Find Designs, Fast
Browse By Category
- Battery Chargers (61)
- Battery 'Fuel Gauge' for DC (9)
- Capacitor Chargers (15)
- Energy Metering for AC (14)
- Ideal Bridge Controller (2)
- Inductive Charging / Wireless Power (14)
- Load or Power Distribution Switches (12)
- OR-ing Controllers (12)
- POE - Power Over Ethernet (32)
- Power Factor Correction (17)
- Power Output Stages (H-Bridge, Half Bridge) (54)
- USB Power Delivery (10)
About Reference Design Library
Instead of searching many manufacturer sites or calling on companies to find and compare designs, now you can search for designs based on the circuit’s performance using Digi-Key’s Reference Design Library.
The Reference Design Library was created in order to:
- Save Engineers time
- Deliver ideas, fast
- Sift through designs based on performance
- Provide designs conveniently accompanied by their schematics
Visit often as new designs are being added weekly and improvements will be made based on your constructive feedback.
Newest 3 Added
FSUSB242GEVB: USB Type-C Port Protection Switch
Manufacturer: ON SemiconductorThe FSUSB242GEVB is an evaluation board for the FSUSB242 USB switch that provides high voltage and surge protection for the HSD+/HSD- lines. Electrical surge is an increasing concern for small form factor connectors such USB microB and USB Type-C™. This evaluation board will demonstrate 2:1 switching while maintaining sufficient signal integrity so the USB 2.0 HS eye diagram can still be passed.
View Design
STEVAL-LLL008V1: 100W, 1.4A @ 70V 90 ~ 265 VAC, 6LoWPAN Mesh Networking
Manufacturer: STMicroelectronicsThe STEVAL-LLL008V1 reference design is a dual-stage LED driver with high power factor designed for 100 W LED lighting applications using 6LoWPAN Mesh networking. The front-end flyback converter provides high power factor and low THD and implements CV primary side regulation (PSR) with input from an auxiliary winding on the transformer through the ZCD pin on the HVLED001B controller, so no isolated optocoupler is required. The flyback converter can deliver 105 W with an average 79 V output.
View Design
TDTTP4000W065AN-KIT: 4kW Analog Bridgeless Totem-Pole PFC
Manufacturer: TransphormThe TDTTP4000W065AN-0v1 4kW Analog bridge-less totem-pole power factor correction (PFC) evaluation board. Very high efficiency single-phase AC-DC conversion is achieved with the TP65H035WS, a diode-free Gallium Nitride (GaN) FET bridge with low reverse-recovery charge. Using Transphorm GaN FETs in the fast-switching leg of the circuit and low-resistance MOSFETs in the slow-switching leg of the circuit results in improved performance and efficiency.
View Design
