PE Series
Metal Current Sensor

Metal Current Sensor, Low TCR - PE Series

YAGEO's current sensor low TCR chip resistor PE series is AEC-Q200 qualified for automotive grade requirements. It offers case sizes from 01005 to 4527, resistance range of 5mΩ-1Ω, tolerance of ±0.1%, ±0.5%, ±1%, ±5% and the lowest TCR down to ±50 ppm/°C with power rating from 1/32 W to 7 W.

Features

  • AEC-Q200 qualified
  • Excellent current sensing performance
  • Low power consumption
  • Low thermal EMF (≤0.3 uV/°C)
  • Operation temperature from -55°C to +170°C
  • Low resistances applied to current sensing

Specifications

  • Case size: 01005-4527
  • Tight tolerance: ±0.1%, ±0.5%, ±1%, ±5%
  • Low TCR down to ±50 ppm/°C
  • Resistance: 5 mΩ - 1Ω
  • Power rating: 1/32W ~ 7W

Applications

  • Consumer goods
  • Computer
  • Telecom / Datacom
  • Industrial / Power supply
  • Automotive
  • Alternative energy

Product List



Metal Current Sensor

PE Series

ImageManufacturer Part NumberDescriptionResistanceTolerancePower (Watts)Available QuantityView Details
RES 0.1 OHM 1% 1W 1206PE1206FKE470R1ZRES 0.1 OHM 1% 1W 1206100 mOhms±1%1W3400 - ImmediateView Details
RES 0.005 OHM 1% 1/8W 0805PE0805FRM070R005ZRES 0.005 OHM 1% 1/8W 08055 mOhms±1%0.125W, 1/8W3579 - ImmediateView Details
RES 0.1 OHM 1% 1/2W 0805PE0805FRE470R1ZRES 0.1 OHM 1% 1/2W 0805100 mOhms±1%0.5W, 1/2W7379 - ImmediateView Details
RES 0.1 OHM 1% 1/4W 0805PE0805FRE7W0R1ZRES 0.1 OHM 1% 1/4W 0805100 mOhms±1%0.25W, 1/4W6315 - ImmediateView Details
RES 0.01 OHM 1% 1/2W 0805PE0805FRE470R01ZRES 0.01 OHM 1% 1/2W 080510 mOhms±1%0.5W, 1/2W30654 - ImmediateView Details
RES 0.02 OHM 1% 1/2W 0805PE0805FRE470R02ZRES 0.02 OHM 1% 1/2W 080520 mOhms±1%0.5W, 1/2W15627 - ImmediateView Details
RES 0.005 OHM 1% 1W 1206PE1206FKM470R005ZRES 0.005 OHM 1% 1W 12065 mOhms±1%1W7230 - ImmediateView Details
RES 0.01 OHM 1% 1/2W 1206PE1206FKF7W0R01ZRES 0.01 OHM 1% 1/2W 120610 mOhms±1%0.5W, 1/2W3730 - ImmediateView Details
RES 0.04 OHM 1% 1W 1206PE1206FKE470R04ZRES 0.04 OHM 1% 1W 120640 mOhms±1%1W3432 - ImmediateView Details
RES 0.1 OHM 1% 1/5W 0603PE0603FRE7W0R1ZRES 0.1 OHM 1% 1/5W 0603100 mOhms±1%0.2W, 1/5W8935 - ImmediateView Details
