PU Series
Metal Current Sensor


Automotive Grade Current Sensor Shunt Resistor - PU Series

YAGEO's PU series shunt resistor is a perfect solution for applications where high precision and high power current sensing components are required. E-beam welding process is introduced to combine the central metal alloy and Copper (Cu) together at the terminations. The central open-air design is the key to achieving excellent heat dissipation.

The PU series features resistance from 0.2 mΩ to 5 mΩ, with high power (10 W), high precision (1%), a low temperature coefficient of resistance (TCR 75 ppm/°C), low thermal EMF, excellent heat dissipation and a capability to sense minimal current. The YAGEO PU series offers high performance, a wide range of sizes (2512, 3921, 5931), versatility and fully meets the requirements of customers in different applications.

Features

  • AEC-Q200 qualified
  • Withstand high temperature and high humidity
  • Excellent heat dissipation
  • Low thermal EMF
  • Operation temperature from -65°C to +275°C

Specifications

  • Case size: 2512, 3921 & 5931
  • High rated power 3 ~ 10 W
  • Low TCR down to 75 ppm/°C
  • Resistance: 0.2 mΩ - 5 mΩ

Applications

  • Power system
  • Automotive
  • Telecommunications
  • Industrial equipment

Resources

Product List



Metal Current Sensor

PU Series

ImageManufacturer Part NumberDescriptionResistanceTolerancePower (Watts)Available QuantityView Details
RES SMD 500 UOHM 1% 9W 3921PU3921FKNP90U5LRES SMD 500 UOHM 1% 9W 39210.5 mOhms±1%9W1939 - ImmediateView Details
METAL SHUNT RESISTOR 3921 1% 175PU3921FKNP90U2LMETAL SHUNT RESISTOR 3921 1% 1750.2 mOhms±1%9W1075 - ImmediateView Details
RES SMD 300 UOHM 1% 9W 3921PU3921FKNP90U3LRES SMD 300 UOHM 1% 9W 39210.3 mOhms±1%9W875 - ImmediateView Details
RES 0.001 OHM 1% 5W 2512PU2512FKNP50R001LRES 0.001 OHM 1% 5W 25121 mOhms±1%5W5851 - ImmediateView Details
RES 0.002 OHM 1% 5W 2512PU2512FKMP50R002LRES 0.002 OHM 1% 5W 25122 mOhms±1%5W4565 - ImmediateView Details
RES 0.003 OHM 1% 4W 2512PU2512FKM130R003LRES 0.003 OHM 1% 4W 25123 mOhms±1%4W3178 - ImmediateView Details
RES 0.004 OHM 1% 3W 3921PU3921FKM130R004LRES 0.004 OHM 1% 3W 39214 mOhms±1%3W1111 - ImmediateView Details
METAL SHUNT RESISTOR 3921 1% 175PU3921FKNP50U4LMETAL SHUNT RESISTOR 3921 1% 1750.4 mOhms±1%5W2902 - ImmediateView Details
RES 0.004 OHM 1% 5W 3921PU3921FKMP50R004LRES 0.004 OHM 1% 5W 39214 mOhms±1%5W1540 - ImmediateView Details
RES 0.001 OHM 1% 9W 3921PU3921FKMP90R001LRES 0.001 OHM 1% 9W 39211 mOhms±1%9W4172 - ImmediateView Details
RES SMD 200 UOHM 1% 9W 3921PU3921FKOP90U2LRES SMD 200 UOHM 1% 9W 39210.2 mOhms±1%9W3065 - ImmediateView Details
METAL SHUNT RESISTOR 3921 1% 175PU3921FKNP90U4LMETAL SHUNT RESISTOR 3921 1% 1750.4 mOhms±1%9W11484 - ImmediateView Details
RES 300 UOHM 1% 6W 2512PU2512FKGP60U3LRES 300 UOHM 1% 6W 25120.3 mOhms±1%6W3948 - ImmediateView Details
RES 0.004 OHM 1% 4W 2512PU2512FKM130R004LRES 0.004 OHM 1% 4W 25124 mOhms±1%4W8000 - ImmediateView Details
RES 0.002 OHM 1% 3W 3921PU3921FKM130R002LRES 0.002 OHM 1% 3W 39212 mOhms±1%3W2652 - ImmediateView Details
RES SMD 500 UOHM 1% 3W 3921PU3921FKN130U5LRES SMD 500 UOHM 1% 3W 39210.5 mOhms±1%3W2271 - ImmediateView Details
METAL SHUNT RESISTOR 3921 1% 75PPU3921FKM130U5LMETAL SHUNT RESISTOR 3921 1% 75P0.5 mOhms±1%3W7981 - ImmediateView Details
METAL SHUNT RESISTOR 3921 1% 175PU3921FKNP50U2LMETAL SHUNT RESISTOR 3921 1% 1750.2 mOhms±1%5W12903 - ImmediateView Details
RES 0.001 OHM 1% 5W 5931PU5931FKMT50R001LRES 0.001 OHM 1% 5W 59311 mOhms±1%5W5903 - ImmediateView Details
RES 0.001 OHM 1% 5W 3921PU3921FKMP50R001LRES 0.001 OHM 1% 5W 39211 mOhms±1%5W5636 - ImmediateView Details
