R5 Series Illuminated Rocker Switches
The R5 Series rocker switches, available in both illuminated and non-illuminated versions, are .850 inches in width and are designed to snap into the panel. They are double pole double throw and work great in industrial, audio/visual and lighting ballast applications. This series rocker switch also has horse power ratings, up to 1HP.
SPECIFICATIONS
- Mechanical Life: 30,000 Cycles
- Electrical Life: 10,000 Cycles
- Contact Resistance: 20 mΩ (Initial)
- Insulation Resistance: > 1,000 MΩ at 500 VDC
- Dielectric Strength: > 1,500 VVAC 1
- Operating Temperature:-20°C to 55°C
- Stafety Standard Approval: UL, CSA, VDE
WB2 Series 20 Amp Power Rocker Switches
The WB2 series high amp rocker switch has a panel cutout of 22 mm x 30 mm and an internal dust and water protection seal, rated to IP55.
SPECIFICATIONS
- Electrical Life: 6,000 cycles
- Contact Resistance: 50 mΩ Max.
- Insulation Resistance: 500 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 min.
- Operating Temperature: -20°C to 65°C Min.
- Ingress Protection: IP55 Standard
RVW Series Full Size Power Rocker Switches
The RVW series high power rated heavy duty full size rocker switch features an internal dust and water protection seal, rated to IP54. Glossy finish option and multiple marking options and switch functions.
SPECIFICATIONS
- Electrical Life: 6,000 cycles
- Contact Resistance: 50 mΩ Max.
- Insulation Resistance: 800 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 min.
- Operating Temperature: 0°C to 55°C
- Ingress Protection: IP54 Standard
PB1973 Series Snap in, Illuminated, Panel Mount Pushbutton
These rectangular illuminated panel mount pushbutton switches come in many colors. The PB1973 series switches offer many options for you at a high rating up to 15 A. These pushbuttons are great for telecommunications, performance audio, external hard drives and modems, networking, computers, servers, instrumentation and low power on/off designs.
SPECIFICATIONS
- Electrical Rating: 50 mA at 12 VDC
- Electrical Life: ≥10,000 Cycles
- Mechanical Life: ≥30,000 Cycles
- Contact Resistance: < 20 mΩ
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: > 1,500V
- Operating Temperature: -10°C to 55°C
- Contact Rating: 15 A 250 VAC UL Listed;
10 A 250 VAC VDE Listed
PA4 Series Illuminated, Power Pushbutton Switches
The PA4 series power pushbutton switch is durable, robust and economical. It features the popular 13mm x 19mm cutout and has high power ratings, offers both standard and water resistant versions, and full illuminations options.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 20 mΩ Min. at 1 A 5 V VDC
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1,000 VAC for 1 Minute
- Operating Temperature: -20°C to 65°C [UR, cUR, CSA]; -20°C to 125°C [ENEC]
LP1 Series Illuminated, Round Pushbutton with Multiple Color Options
This latest round pushbutton switch is a panel mount illuminated LED switch. The LP1 series illuminated switch is available with multiple illumination color options with a momentary pushbutton function.
SPECIFICATIONS
- Contact Rating: 100 mA 30 VDC
- Electrical Life: 50,000 Cycles
- Contact Resistance: 50 mΩ Inital Max.
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 500 VAC
- Force: 250 gf ± 100 gf
- Operating Temperature: -40°C to 85°C
- Storage Temperature: -40°C to 85°C
- Travel: 1.8 mm ± 0.3 mm
LA Series Sealed, Illuminated Pushbutton Switches
The LA series illuminated pushbutton switches have an IP65 rating. They come in up to 4 poles and a variety of color options. Now they are available in a Flush Mount configuration - with an appealing aluminum bezel.
SPECIFICATIONS
- Electrical Life: ≥50,000 Cycles
- Mechanical Life: ≥100,000 Cycles
- Contact Resistance: 100 mΩ Max. Typical, Initial at 2-4 VDC
- Insulation Resistance: > 1,000 MΩ
- Dielectric Strength: > 1,500 V for 1 Minute; >3,000 V Between Poles
- Operating Temperature: -20°C to 55°C
- Actuation Force: 300 g/pole
- Degree of Protection: IP65
R4 Series Illuminated Rocker Switches
The R4 series rocker switches are available in both illuminated and non-illuminated versions, with neon or incandescent lamps. They are power rated and UL approved. There are three housing colors to choose from: black, white and gray. Multiple marking options and SPST or SPDT functions.
SPECIFICATIONS
- Electrical Life: 6,000 Cycles
- Mechanical Life: 30,000 Cycles
- Contact Resistance: 20 mΩ Max. Typical Initial at 2-4 VDC
- Insulation Resistance: > 1,000 MΩ
- Dielectric Strength: > 1,500 V for 1 Minute Between Terminals
- Operating Temperature: -20°C to 55°C
- Safety Standard Approval: UL, VDE
- Contact Contact: Versions D,G,I - 10 A 250 V, 15 A 125 VAC;
Versions A,B,C,E,F,H, J - 16 A 250 V, 20 A 125 VAC
RSC Series Power Rocker Switch With Illumination and Bi-Color Actuator Options
The RSC series illuminated power rocker switch has a bi-color actuator, and 4 bodies to cover many popular cutouts. High current capacity.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 20 mΩ Max. at 1 A 5 VDC
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1,000 VAC for 1 Minute
300 Series Miniature Rocker and Paddle Switches
The 300 Series miniature rocker and paddle switches offer a variety of model styles and actuator options. These rocker switches are available in up to 4 poles they have multiple termination options, and a snap-in panel mount option is available also.
SPECIFICATIONS
- Mechanical Life: 40,000 Make-and-Break Cycles
- Contact Resistance: 10 mΩ Max. Initial
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: 1,000 V RMS for 1 Minute
- Operating Temperature: -30°C to 85°C
- Contact Rating: Dependent Upon Contact Material
D16 Series Illuminated Pushbutton Switches
These illuminated pushbutton switches are available with solder lug termination. The P16 series are available with a socket connection and the L16 have pilot indicators. They come in up to 4 poles, have latching and momentary functions, and round, square or rectangular pushbutton heads. Neon, incandescent and LED lamps available.
SPECIFICATIONS
- Electrical Life: 50,000 Cycles
- Mechanical Life: 100,000 Cycles
- Contact Resistance: 100 mΩ Max. Typical; Initial at 2-4 VDC
- Insulation Resistance: > 1,000 MΩ
- Dielectric Strength: > 1,500 V for 1 Minute; > 3,000 V Between Poles
- Operating Temperature: -20°C to 55°C
- Operating Force: 300 g/pole
ULP Series Illuminated Pushbutton
The ULP series illuminated push-button switches provide a positive tactile response. Many LED color options are available, including RGB color options, as well as multiple cap sizes and styles to choose from.
SPECIFICATIONS
- Electrical Life: 200,000 Cycles Silver; 200,000 Cycles Gold
- Contact Resistance: 50 mΩ Silver, 100 mΩ Gold
- Insulation Resistance: > 100 MΩ at 500 VDC
- Dielectric Strength: 1000 VAC for 1 Minute
- Operating Temperature: -40°C to 85°C
- Operating Force: 200 gf ± 100 gf SPDT; 300 gf ± 150 gf DPDT
- Contact Rating: Gold: 0.1 A Max. at 28 VDC; Silver, 0.5 A at 25 VDC; 0.2 A at 250 VAC
R1966 Series Illuminated Rocker Switches
The R1966 Series illuminated rocker switches are available with a variety of colored housings, actuators and LEDs. The panel cut out size is an industry standard size 13 mm x 19.2 mm.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Mechanical Life: 30,000 Cycles
- Contact Resistance: 20 mΩ Typical, Initial
- Insulation Resistance: > 1,000 MΩ
- Dielectric Strength: > 1,500 V for 1 Minute
- Operating Temperature: -30°C to 65°C
R6 Series Slim-line Rocker Switches
The R6 Series rocker switches are available in SPST and offer a width of .378 inch, presented in a slim-line package design.
SPECIFICATIONS
- Electrical Rating: 10,000 Cycles
- Life Expectancy: 50,000 Cycles
- Contact Resistance: < 20mΩ (Initial)
- Insulation Resistance: > 1,000 MΩ at 500 VDC
- Dielectric Strength: > 1,500 VAC for 1 Minute (Initial)
- Operating Temperature: -20°C to 65°C
PP1 Series Push Pull Pushbutton Switches
The PP1 series pushbutton / detector switch features a push pull function and various terminal options. This switch has high ratings with UL approvals, up to 16 A with 1HP. The PP1 series push-pull switch acts as a door-interlock switch or detector switch. It has a very high tolerance for activation, and the ability to include push and pull activation for manual maintenance. This switch is available with either a short or long body, and fits a panel cutout size of 36.5 mm x 13.5 mm. This door interlock switch is used in a variety of applications including slot machines, kiosk and gaming equipment, where a technician can come and service the machine, pushing or pulling the switch as needed to power on or off the unit. It can also be found in appliances, HVAC and security devices.
SPECIFICATIONS
- Electrical Rating:
- 16 A 125 VAC [cULus]
- 12 A 250 VAC [cULus]
- 1HP 125/250 VAC [cULus]
- Electrical Life: 6,000 Cycles [cULus]
- Contact Resistance: 50 mΩ Max.
- Operating Temperature: 0°C to 85°C
PP1 Series Push Pull Pushbutton Switches
The PP2 series push button | detector switch is a power rated push-pull switch with momentary functions, and can act as a door interlock switch. There are various actuator and terminal options, with high ratings and UL approvals at up to 16A and 1HP. The PP2 series switch is NOW AVAILABLE with a 3/16 x .020 inch terminals. (4.8 mm x .80 mm tabs) It has the ability to include both push and pull activation for manual maintenance. This push pull switch acts as a door interlock switch, and can be used in a variety of applications where a service technician needs to be able to turn on and off the machine while the technician is working on the back panel (such as a kiosk, slot machine, or other gaming equipment). It also can be found in commercial appliances, HVAC equipment and security devices.
SPECIFICATIONS
- Electrical Life: 6,000 Cycles
- Mechanical Life: 50,000 Cycles
- Contact Resistance: 10 mΩ Max.
- Insulation Resistance: 100 MΩ Min.
- Operating Temperature: 0°C to 85°C
- Panel Cutout: 13.5 mm x 36 mm
- Function: DPDT, On-(On) or On1-On2-(On1)
PR1 Series Round, Illuminated, Power Pushbutton Switches
The PR1 series pushbutton switch is a high power rated switch with UL and VDE approvals. Features for this pushbutton switch include maintained and momentary options, and an optional PVC cap for water and dust protection.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 35 mΩ Max.
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: -20°C to 105°C [UL, cUL]; -20°C to 125°C [VDE]
- Ingress Protection: IP54 with PVC Cap
RP3508 Series Round, Illuminated Pushbutton
The RP3508 series pushbutton is a panel mount switch that comes with green, red or yellow LED options. It is round and has full illumination options.
SPECIFICATIONS
- Electrical Life: ≥6,000 Cycles
- Mechanical Life: ≥20,000 Cycles
- Insulation Resistance: > 1,000 MΩ
- Dielectric Strength: > 1,500 V for 1 Minute
- Operating Temperature: 0°C to 65°C
- Storage Temperature: -25°C to 85°C
- Contact Rating: 3 A 125 VAC; 1.5 A 250 VAC
700 Series Snap-Acting, Panel Mount Push Button Switches
The 700 series push button switches have a snap-in panel mount option. Has a snap acting contact design and multiple termination options.
SPECIFICATIONS
- Ratings: 1 A 250 VAC, 3 A 120 VAC or 28 VDC
- Electrical Life: 50,000 Cycles Typical
- Contact Resistance: 10 mΩ Max. Typical at 2-4 VDC; 100 mA For Both Silver and Gold Plated Contacts
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: 1,000 V RMS at Sea Level
- Operating Temperature: -30°C to 85°C
- Operating Force: 200 gf ± 50 gf
RA4 Series Power Rocker Switches UL Rated
The RA4 series illuminated power rocker switch has ratings up to 16 A and UL, ENEC approvals. This RA4 series power switch has curved and paddle actuator options, and a PVC cap for dust and water protection.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 35 mΩ Max.
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: -20°C to 105°C [UL, cUL]; -20°C to 125°C [SEMKO, ENEC]
- Ingress Protection: IP54 with PVC Cap
RR3112 Series Round Rocker, Illuminated Panel Mount
Introducing the RR3112 series round panel-mount rocker in illuminated and non-illuminated verions. There are two illuminated versions of the RR3112 series rocker switch - Option "B" has NEON wired inline to produce an illuminated actuator, while the "L" option has an LED wired separate and viewable through a window on the actuator.
SPECIFICATIONS
- Electrical Life: 6,000 Cycles
- Mechanical Life: 20,000 Cycles
- Contact Resistance: 50 MΩ (Initial)
- Insulation Resistance: 100 mΩ at 500 VDC
- Dielectric Strength: 1,500 V Min. for 1 Minute
- Operating Temperature: 0°C to 65°C
- Contact Rating: 16 A 125 VAC; 10 A 250 VAC
RR3402 Series Panel Mount, Paddle Style Rocker
The RR3402 rocker switches has an ergonomic feel with multiple circuit options. The RR3402 rocker switch is great for the industrial, audio visual and lighting ballast industries.
SPECIFICATIONS
- Electrical Life: 6,000 Cycles
- Mechanical Life: 20,000 Cycles
- Contact Resistance: 50 mΩ Max. (Initial)
- Insulation Resistance: 100 MΩ at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: 0°C to 65°C
- Contact Rating: 6 A 125 VAC; 3 A 250 VAC
ST1 Series High Amp Toggle Switches
The ST1 series high amp toggle switches feature heavy rating with UL approvals and a rubber boot for water and dust protection. Momentary or maintained functions available. Rated up to 20 A.
SPECIFICATIONS
- Electrical Life: 6,000 Cycles
- Contact Resistance: 500 mΩ Max.
- Insulation Resistance: 800 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: -20°C to 85°C
100 Series Miniature Toggle Switches
The 100 Series miniature toggle switches offer numerous actuator options and termination options including right angle PC mount. These toggle switches offer up to 4 poles. They are PCB mounted and are available in through whole or right angle termination. NOW available with a locking toggle!!
SPECIFICATIONS
- Electrical Life: 6,000 at Full Power
- Mechanical Life: 40,000 Make-and-Break Cycles
- Contact Resistance: 10 mΩ Max. initial
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: 1,000 V RMS at Sea Level
- Operating Temperature: -30°C to 85°C
- Torque: Max. 5kg·cm (70 ounce·inch)
- Contact Rating: Dependent on Contact Material
700A Series IP-67 Sealed Pushbutton Switches
This sealed pushbutton switch has a snap acting contact design and comes with multiple termination options. This 700A series pushbutton switch is sealed to IP67 ratings and offers you the option of gold or silver contacts.
SPECIFICATIONS
- Life Expectancy: 50,000 Cycles
- Contact Resistance: 20 mΩ
- Insulation Resistance: 1000 MΩ
- Dielectric Strength: 1500 V RMS
- Operating Temperature: -30°C to 85°C
- Contact Rating: Gold - 0.4 VA 20 V (AC or DC) Max.; Silver - 3 A 120 VAC or 28 VDC, 1 A 250 VAC
RB4 Series Illuminated, Dual Power Rocker Switches
The RB4 series dual rocker switch has two switches built into one panel mounted, UL rated body. It snaps into an industry standard 22 mm x 30 mm panel cutout.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 35 mΩ Max.
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: -20°C to 85°C Min.
- Ingress Protection: IP54 with PVC Cap
RR3130 Series Round Rocker for Panel Mounting
This RR3130 series round rocker switch is panel mounted and has a light, ergonomic feel which is great in designing your applications. Markets include use in telecommunications, audio/visual, instrumentation, computers and peripherals, and more.
SPECIFICATIONS
- Electrical life: 6,000 Cycles
- Mechanical Life: 20,000 Cycles
- Contact Resistance: 50 mΩ
- Insulation Resistance: 100 MΩ Min. at 500 VDC
- Dielectric Strength: 1500 V Min. for 1 Minute
- Operating Temperature: 0°C to 65°C
- Storage Temperature: -25°C to 85°C
- Termination: Solder Lug, Silver-Plated
- Contact Rating: 10 A 125 VAC; 6 A 250 VAC
RR1 Series Illuminated, Round Power Rocker Switch
The RR1 series is an aesthetically designed power rocker switch with a round body and full illumination. It is a single pole rocker switch with many functions.
SPECIFICATIONS
- Electrical Life: 10,000 Cycles
- Contact Resistance: 35 mΩ Max. at 50 VAC
- Insulation Resistance: 100 MΩ Min. at 500 VAC
- Dielectric Strength: 1,500 VAC for 1 Minute
- Operating Temperature: -20°C to 105°C [UL, cUL]; -20°C to 125°C [SEMKO, ENEC]
PV6 Series Illuminated, Sealed, Long Life Anti-vandal Switches
The PV6 series illuminated anti vandal switches now offers an RGB LED option. The RGB LED feature combines colors red, green and blue to produce over 16 million hues of light, making the color options nearly unlimited.
SPECIFICATIONS
- Rating: 2 A 48 VDC
- Electrical Life: 50,000 Cycles
- Mechanical Life: 1,000,000 Cycles
- Contact Resistance: 50 mΩ Max.
- Insulation Resistance: 1,000 MΩ Min
- Dielectric Strength: 2,000 VAC
- Operating Temperature: -20°C to 55°C
- Ingress Protection: IP65
- Panel Cutout: 16 mm Diameter
200 Series Sub-miniature Toggle Switches
The 200 Series sub-miniature toggle switches are offered in both SPDT and DPDT. These switches come with a variety of switching functions and bushing options. Eight different termination options are available.
SPECIFICATIONS
- Electrical Life: 6,000 at Full Power
- Mechanical Life: 30,000 Make-and-Break Cycles
- Contact Resistance: 10 mΩ Max. Initial for Both Silver and Gold Plated Contacts
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: 1,000 V RMS at Sea Level
- Operating Temperature: -30°C to 85°C
- Contact Rating: Dependent on Contact Material
800 Series Sub-Miniature Pushbutton Switches
The 800 series subminiature pushbutton switches have a snap-in panel mount option and a butt contact design. These tiny pushbutton switches offer a variety of termination options and work great in the telecommunications, networking, computers, performance audio, instrumentation and low power on/off design applications.
SPECIFICATIONS
- Electrical Life: 50,000 Cycles Typical
- Contact Resistance: 10 mΩ Max. Typical at 2-4 VDC; 100 mA For Both Silver and Gold Plated Contacts
- Insulation Resistance: 1,000 MΩ Min.
- Dielectric Strength: 1,000 V RMS at Sea Level
- Operating Temperature: -30°C to 85°C
- Operating Force: 200 gf ± 50 gf
Settings
Fast Delivery
Free Shipping
Incoterms
Payment Types
Marketplace Product
Hong Kong, China
