Cut the Cord with Wireless Power Solutions

Wireless Power Coils, WE-WPCC, offer the best performance with highest Q-factor and lowest RDC values.

Wireless Power Coils, WE-WPCC, offer the best performance with highest Q-factor and lowest RDC values. Standardized coils, according to Wireless Power Consortium (WPC), and other off-the-shelf components from 50 mW to 400 W are available. Customized solutions for wireless power coils up to 11 kW are possible. Therefore, Würth Elektronik offers the industry‘s broadest portfolio of wireless power transfer coils.

Applications:

  • Smart watches, fitness tracker, Digital cameras, baby phone, remote control, smartphone sleeves, watertight products
  • Portable devices used in a clean area, where connectors pose a risk of polluting e.g. medical facilities and (industrial) clean rooms
  • Devices with a large number of mating cycles to avoid connector damage
  • Headsets
  • Portable media players

Related Videos

31:13

WEbinar Powered by DigiKey: Design and Optimization of a Simultaneous WPT and NFC System

In this WEbinar, a system, which implements an inductive wireless power transfer (WPT) system with simultaneous operating near field communication (NFC), is presented. The webinar describes the design goals and the optimization steps.



2:35

Würth Elektronik illustrates Wireless Power Transfer (WPT)

WIRELESS POWER TRANSFER COILS WE-WPCC offer the best performance with highest Q-factor and lowest RDC values. Standardized coils, according to Wireless Power Consortium (WPC), and other off-the-shelf components from 50 mW to 200 W are available.



1:05

Würth Wireless Power Charging Coils | DigiKey Daily

Würth Elektronik wireless power charging coils (WE-WPCC) are easy to mount, space saving, and wireless power charging coils. They have low DC resistance, are high Q, and are Qi-compliant up to 15 W. Flexible ferrite shielding helps the charging coils to suppress noise levels above 1 MHz. Wurth wireless power charging coils are available at DigiKey.

Trilogy of Wireless Power Transfer

Trilogy of Wireless Power Transfer

Wurth Electronics’ Trilogy of Wireless Power Transfer is a design guide providing information to understand wireless power from basic principles to advanced applications

View Details

Resources


Transmitter
 Receiver

760 308 101
Qi-A1
760 308 105
Qi-A5
760 308 106
Qi-A6
760 308 110
Qi-A10
760 308 100 110
Qi-A10
760 308 111
Qi-A11
760 308 100 111
Qi-A11
760 308 104 113
Qi-A13
760 308 104 119
Qi-A19
760 308 104 120
Qi-A28
760 308 141
Qi-A29
760 308 100 141
Qi-A29
760 308 103 102
Qi-MP-A2
760 308 102 142
works with Qi Tx IC`s / 5V
760 308 100 143
works with Qi Tx IC`s / 5V
760 308 101 103
works with Qi Tx IC`s / 5V
760 308 101 104
works with Qi Tx IC`s / 5V
760 308 101 105
works with Qi Tx IC`s / 5V
760 308 101 302
works with Qi Tx IC`s / 5V
760 308 101 304
works with Qi Tx IC`s / 5V
760 308 101 141
Qi-A29 / 5V
760 308 103 146
Qi-MP-A8 / 5V
760 308 103 147
Qi-MP-A8 3-coil array / 5V
760 308 103 145
Qi-MP-A6 / 5V
760 308 101 107
works with Qi Tx IC`s / 5V
760 308 101 106
works with Qi Tx IC`s / 5V
760 308 103 109
Oi-MP-A9 / 5V
760 308 103 149
Qi-MP-A9 3-coil array / 5V
760 308 102 144
works with Qi Tx IC`s / 5V
760 308 102 308
works with Qi Tx IC`s / 5V
760 308 103 148
Qi-A28 2-coil array / 5V

Legend

= useable = not working = possible

Related Products

Array

圖片製造商零件編號說明功能電感值現有數量價格查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103149WE-WPCC WIRELESS POWER CHARGING發送器10.2µH、9.8µH、10.2µH16 - 即時供貨$174.24查看詳情
TX 3 COIL 1 LAYER 10A760308106TX 3 COIL 1 LAYER 10A發送器12.5µH、11.5µH、12.5µH17 - 即時供貨$259.96查看詳情
TX 2 COIL 1 LAYER 12UH 11.5UH 8A760308104119TX 2 COIL 1 LAYER 12UH 11.5UH 8A發送器12µH、11.5µH2 - 即時供貨$143.04查看詳情
WE-WPCC WIRELESS POWER CHARGING760308104120WE-WPCC WIRELESS POWER CHARGING發送器6.9µH、6.4µH、6.9µH1 - 即時供貨$227.44查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103147WE-WPCC WIRELESS POWER CHARGING發送器8.5µH、7.5µH、8.5µH8 - 即時供貨$166.52查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103148WE-WPCC WIRELESS POWER CHARGING接收器、發送器6.9µH、6.4µH3 - 即時供貨$166.52查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103145WE-WPCC WIRELESS POWER CHARGING發送器11.3µH4 - 即時供貨$166.52查看詳情

Receiver

圖片製造商零件編號說明功能電感值現有數量價格查看詳情
RX 1 COIL 1 LAYER 10UH 4.5A760308201RX 1 COIL 1 LAYER 10UH 4.5A接收器10µH0 - 即時供貨$51.58查看詳情
RX 1 COIL 1 LYR BIFILAR 12UH760308103202RX 1 COIL 1 LYR BIFILAR 12UH接收器12µH3630 - 即時供貨$47.71查看詳情
RX 1 COIL 1 LAYER 12UH 1.55A760308103203RX 1 COIL 1 LAYER 12UH 1.55A接收器12µH0 - 即時供貨$47.71查看詳情
RX 1 COIL 1 LAYER 16.7UH 1A760308103204RX 1 COIL 1 LAYER 16.7UH 1A接收器16.7µH0 - 即時供貨$47.71查看詳情
RX 1 COIL 1 LAYER 7.5UH 3A760308102210RX 1 COIL 1 LAYER 7.5UH 3A接收器7.5µH100 - 即時供貨$85.80查看詳情
RX 1 COIL 3 LAYER 13UH 0.8A760308101208RX 1 COIL 3 LAYER 13UH 0.8A接收器13µH375 - 即時供貨$77.68查看詳情
TX 1 COIL 1 LAYER 5.3UH 8A760308101302TX 1 COIL 1 LAYER 5.3UH 8A發送器5.3µH21 - 即時供貨$157.73查看詳情
RX 1 COIL 3 LYR BIFILAR 47UH760308101303RX 1 COIL 3 LYR BIFILAR 47UH接收器47µH680 - 即時供貨$89.83查看詳情
RX 1 COIL 1 LYR BIFILAR 8UH 5A760308102207RX 1 COIL 1 LYR BIFILAR 8UH 5A接收器8µH0 - 即時供貨$77.68查看詳情
RX 1 COIL 1 LYR BIFILAR 11UH760308103205RX 1 COIL 1 LYR BIFILAR 11UH接收器11µH3208 - 即時供貨$64.29查看詳情
RX 1 COIL 1 LAYER 7.5UH 1.55A760308103206RX 1 COIL 1 LAYER 7.5UH 1.55A接收器7.5µH0 - 即時供貨$77.68查看詳情
RX 1 COIL 1 LAYER 7.3UH 2.5A760308103211RX 1 COIL 1 LAYER 7.3UH 2.5A接收器7.3µH15 - 即時供貨$63.80查看詳情
RX 1 COIL 1 LAYER 5.4UH 2A760308102212RX 1 COIL 1 LAYER 5.4UH 2A接收器5.4µH21 - 即時供貨$63.80查看詳情
RX 1 COIL 1 LAYER 7.9UH 1.7A760308102213RX 1 COIL 1 LAYER 7.9UH 1.7A接收器7.9µH117 - 即時供貨$63.80查看詳情
RX 1 COIL 3 LAYER 26UH 1.1A760308101214RX 1 COIL 3 LAYER 26UH 1.1A接收器26µH1211 - 即時供貨$58.95查看詳情
RX 1 COIL 1 LAYER 14.3UH 3A760308103215RX 1 COIL 1 LAYER 14.3UH 3A接收器14.3µH66 - 即時供貨$65.61查看詳情
RX 1 COIL 6 LAYER 7.2UH 500MA760308101216RX 1 COIL 6 LAYER 7.2UH 500MA接收器7.2µH493 - 即時供貨$65.03查看詳情
RX 1 COIL 6 LAYER 24.2UH 400MA760308101217RX 1 COIL 6 LAYER 24.2UH 400MA接收器24.2µH64 - 即時供貨$65.03查看詳情
RX 1 COIL 1 LAYER 11.8UH 700MA760308101219RX 1 COIL 1 LAYER 11.8UH 700MA接收器11.8µH262 - 即時供貨$58.54查看詳情
RX 1 COIL 3 LAYER BIFILAR 12.6UH760308101220RX 1 COIL 3 LAYER BIFILAR 12.6UH接收器12.6µH1326 - 即時供貨$62.81查看詳情

Transmitter

圖片製造商零件編號說明功能電感值現有數量價格查看詳情
WE-WPCC WIRELESS POWER CHARGING760308101311WE-WPCC WIRELESS POWER CHARGING發送器5.8µH52 - 即時供貨$176.70查看詳情
WE-WPCC WIRELESS POWER CHARGING760308101411WE-WPCC WIRELESS POWER CHARGING發送器6.3µH3 - 即時供貨$94.84查看詳情
WE-WPCC WIRELESS POWER CHARGING760308101410WE-WPCC WIRELESS POWER CHARGING發送器24µH2 - 即時供貨$106.74查看詳情
TX 1 COIL 2 LAYER 24UH 6A760308101TX 1 COIL 2 LAYER 24UH 6A發送器24µH0 - 即時供貨$105.90查看詳情
TX 1 COIL 2 LYR BIFIL 6.3UH 13A760308111TX 1 COIL 2 LYR BIFIL 6.3UH 13A發送器6.3µH2425 - 即時供貨$100.50查看詳情
TX 1 COIL 2 LAYER 24UH 6A760308110TX 1 COIL 2 LAYER 24UH 6A發送器24µH82 - 即時供貨$100.50查看詳情
TX 1 COIL 2 LYR BILFILAR 6.3UH760308105TX 1 COIL 2 LYR BILFILAR 6.3UH發送器6.3µH13 - 即時供貨$100.50查看詳情
TX 1 COIL 2 LAYER 24UH 6A760308100110TX 1 COIL 2 LAYER 24UH 6A發送器24µH1334 - 即時供貨$100.50查看詳情
TX 1 COIL 1 LAYER 6.3UH 13A760308100111TX 1 COIL 1 LAYER 6.3UH 13A發送器6.3µH750 - 即時供貨$100.50查看詳情
TX 1 COIL 1 LAYER 6.5UH 3A760308101103TX 1 COIL 1 LAYER 6.5UH 3A發送器6.5µH0 - 即時供貨$89.83查看詳情
TX 1 COIL 2 LAYER 10UH 9A760308141TX 1 COIL 2 LAYER 10UH 9A發送器10µH17 - 即時供貨$177.69查看詳情
TX 1 COIL 2 LAYER 10UH 9A760308100141TX 1 COIL 2 LAYER 10UH 9A發送器10µH32 - 即時供貨$177.69查看詳情
TX 1 COIL 1 LAYER 12UH 7A760308104113TX 1 COIL 1 LAYER 12UH 7A發送器12µH206 - 即時供貨$120.46查看詳情
TX 1 COIL 2 LAYER 3.3UH 3A760308101105TX 1 COIL 2 LAYER 3.3UH 3A發送器3.3µH0 - 即時供貨$97.05查看詳情
TX 1 COIL 1 LYR BIFIL 5.8UH 18A760308102142TX 1 COIL 1 LYR BIFIL 5.8UH 18A發送器5.8µH37 - 即時供貨$158.14查看詳情
TX 1 COIL 2 LAYER 6UH 12A760308100143TX 1 COIL 2 LAYER 6UH 12A發送器6µH9 - 即時供貨$158.14查看詳情
TX 1 COIL 1 LAYER 6.3UH 6A760308101304TX 1 COIL 1 LAYER 6.3UH 6A發送器6.3µH87 - 即時供貨$138.60查看詳情
TX 1 COIL 2 LAYER 6.3UH 2.5A760308101104TX 1 COIL 2 LAYER 6.3UH 2.5A發送器6.8µH1454 - 即時供貨$97.05查看詳情
TX 1 COIL 1 LAYER 10UH 7A760308103102TX 1 COIL 1 LAYER 10UH 7A發送器10µH73 - 即時供貨$148.04查看詳情
WE-WPCC WIRELESS POWER CHARGING760308102144WE-WPCC WIRELESS POWER CHARGING發送器19.5µH0 - 即時供貨$139.98查看詳情
WE-WPCC WIRELESS POWER CHARGING760308102308WE-WPCC WIRELESS POWER CHARGING發送器3µH20 - 即時供貨$125.55查看詳情

WPT/NFC Combination Coil

圖片製造商零件編號說明功能電感值現有數量價格查看詳情
WE-WPCC WIRELESS POWER CHARGING760308101312WE-WPCC WIRELESS POWER CHARGING發送器24µH、700nH4 - 即時供貨$88.10查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103305WE-WPCC WIRELESS POWER CHARGING接收器8.8µH、1.4µH5 - 即時供貨$112.16查看詳情
WE-WPCC WIRELESS POWER CHARGING760308102306WE-WPCC WIRELESS POWER CHARGING接收器8µH、1.4µH0 - 即時供貨$133.92查看詳情
WE-WPCC WIRELESS POWER CHARGING760308103307WE-WPCC WIRELESS POWER CHARGING接收器7.8µH、1.6µH50 - 即時供貨$92.29查看詳情
