High Voltage Fast Acting Brick Fuses - 1145HV/1350HV Series
Eaton's 450 VDC to 600 VDC high voltage 1145HV/1350HV series brick fuses provide primary and secondary circuit protection
Eaton Bussmann series 1145HV and 1350HV fast-acting fuses provide reliable overcurrent protection up to 7.5 A for high voltage ranging from 450 VDC to 600 VDC. Both product families are available in surface mount printed circuit board packages with the 1145HV in 11 mm x 4.5 mm footprint and 1350HV in 13 mm x 5.0 mm footprint. The SMD package helps reduce required PCB space and ease of use in PCB assembly pick and place machines. They can be used in a wide variety of applications, including energy storage, UPS, and Telecom, among others.
Resources
Features
- High voltage fast-acting brick fuse
- Ceramic tube, silver-plated cap construction
- Up to 500 VDC voltage rating (1145HV) and 600 VDC (1350HV)
Applications
- Primary and secondary circuit protection:
- Server and telecom systems, including 380 VDC distribution
- Single-phase and 3-phase UPS
- 380 VDC DC/DC converters
- High voltage DC/DC conversion
- Power factor correction
- Capacitor output protection
1145HV Series
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
 |  | TR-1145HV1-R | FUSE BRD MT 1A 350VAC 500VDC SMD | 2239 - Immediate | $31.78 | View Details |
| | TR-1145HV1-25-R | FUSE BRD MNT 1.25A 350VAC 500VDC | 893 - Immediate | $25.52 | View Details |
| | TR-1145HV1-6-R | FUSE BRD 1.6A 350VAC 500VDC 2SMD | 845 - Immediate | $25.52 | View Details |
| | TR-1145HV2-5-R | FUSE BRD MT 2.5A 350VAC 500VDC | 816 - Immediate | $25.52 | View Details |
| | TR-1145HV3-15-R | FUSE BRD MNT 3.15A 350VAC 500VDC | 0 - Immediate | $33.42 | View Details |
| | TR-1145HV2-R | FUSE BRD MT 2A 350VAC 500VDC SMD | 496 - Immediate | $25.52 | View Details |
| | TR-1145HV4-R | FUSE BRD MT 4A 350VAC 450VDC SMD | 925 - Immediate | $25.52 | View Details |
| | TR-1145HV5-R | FUSE BRD MT 5A 350VAC 450VDC SMD | 832 - Immediate | $31.28 | View Details |
1350HV Series
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
|  | TR-1350HV1-R | FUSE BRD MT 1A 350VAC 600VDC SMD | 0 - Immediate | $36.47 | View Details |
| | TR-1350HV1-25-R | FUSE BRD MNT 1.25A 350VAC 600VDC | 193 - Immediate | $34.82 | View Details |
| | TR-1350HV1-6-R | FUSE BRD MT 1.6A 350VAC 600VDC | 949 - Immediate | $34.82 | View Details |
| | TR-1350HV2-R | FUSE BRD MT 2A 350VAC 600VDC SMD | 34 - Immediate | $34.82 | View Details |
| | TR-1350HV2-5-R | FUSE BRD 2.5A 350VAC 600VDC 2SMD | 510 - Immediate | $34.82 | View Details |
| | TR-1350HV3-15-R | FUSE BRD 3.15A 350VAC 600VDC SMD | 2214 - Immediate | $34.82 | View Details |
| | TR-1350HV4-R | FUSE BRD MT 4A 350VAC 500VDC SMD | 623 - Immediate | $34.82 | View Details |
| | TR-1350HV5-R | FUSE BRD MT 5A 350VAC 500VDC SMD | 6139 - Immediate | $34.82 | View Details |
|  | TR-1350HV6-R | FUSE BRD MT 6A 350VAC 400VDC SMD | 903 - Immediate | $35.97 | View Details |
|  | TR-1350HV7-5-R | FUSE BRD MT 7.5A 350VAC 400VDC | 401 - Immediate | $35.97 | View Details |
Published: 2021-10-25
