Tile-Matching Game on the Adafruit Metro RP2350

Auto-reload is off.
Running in safe mode! Not running saved code.

CircuitPython is in safe mode because you pressed the reset button during boot. Press again to exit safe mode.

Press any key to enter the REPL. Use CTRL-D to reload.

# SPDX-FileCopyrightText: 2025 Melissa LeBlanc-Williams for Adafruit Industries
# SPDX-License-Identifier: MIT
"""
An implementation of a match3 jewel swap game. The idea is to move one character at a time
to line up at least 3 characters.
"""
import time
from displayio import Group, OnDiskBitmap, TileGrid, Bitmap, Palette
from adafruit_display_text.bitmap_label import Label
from adafruit_display_text.text_box import TextBox
from eventbutton import EventButton
import supervisor
import terminalio
from adafruit_usb_host_mouse import find_and_init_boot_mouse
from gamelogic import GameLogic, SELECTOR_SPRITE, EMPTY_SPRITE, GAMEBOARD_POSITION

GAMEBOARD_SIZE = (8, 7)
HINT_TIMEOUT = 10  # seconds before hint is shown
GAME_PIECES = 7  # Number of different game pieces (set between 3 and 8)

# pylint: disable=ungrouped-imports
if hasattr(supervisor.runtime, "display") and supervisor.runtime.display is not None:
    # use the built-in HSTX display for Metro RP2350
    display = supervisor.runtime.display
else:
    # pylint: disable=ungrouped-imports
    from displayio import release_displays
    import picodvi
    import board
    import framebufferio

    # initialize display
    release_displays()

    fb = picodvi.Framebuffer(
        320,
        240,
        clk_dp=board.CKP,
        clk_dn=board.CKN,
        red_dp=board.D0P,
        red_dn=board.D0N,
        green_dp=board.D1P,
        green_dn=board.D1N,
        blue_dp=board.D2P,
        blue_dn=board.D2N,
        color_depth=16,
    )
    display = framebufferio.FramebufferDisplay(fb)

def get_color_index(color, shader=None):
    for index, palette_color in enumerate(shader):
        if palette_color == color:
            return index
    return None

# Load the spritesheet
sprite_sheet = OnDiskBitmap("/bitmaps/game_sprites.bmp")
sprite_sheet.pixel_shader.make_transparent(
    get_color_index(0x00ff00, sprite_sheet.pixel_shader)
)

# Main group will hold all the visual layers
main_group = Group()
display.root_group = main_group

# Add Background to the Main Group
background = Bitmap(display.width, display.height, 1)
bg_color = Palette(1)
bg_color[0] = 0x333333
main_group.append(TileGrid(
    background,
    pixel_shader=bg_color
))

# Add Game grid, which holds the game board, to the main group
game_grid = TileGrid(
    sprite_sheet,
    pixel_shader=sprite_sheet.pixel_shader,
    width=GAMEBOARD_SIZE[0],
    height=GAMEBOARD_SIZE[1],
    tile_width=32,
    tile_height=32,
    x=GAMEBOARD_POSITION[0],
    y=GAMEBOARD_POSITION[1],
    default_tile=EMPTY_SPRITE,
)
main_group.append(game_grid)

# Add a special selection groupd to highlight the selected piece and allow animation
selected_piece_group = Group()
selected_piece = TileGrid(
    sprite_sheet,
    pixel_shader=sprite_sheet.pixel_shader,
    width=1,
    height=1,
    tile_width=32,
    tile_height=32,
    x=0,
    y=0,
    default_tile=EMPTY_SPRITE,
)
selected_piece_group.append(selected_piece)
selector = TileGrid(
    sprite_sheet,
    pixel_shader=sprite_sheet.pixel_shader,
    width=1,
    height=1,
    tile_width=32,
    tile_height=32,
    x=0,
    y=0,
    default_tile=SELECTOR_SPRITE,
)
selected_piece_group.append(selector)
selected_piece_group.hidden = True
main_group.append(selected_piece_group)

# Add a group for the swap piece to help with animation
swap_piece = TileGrid(
    sprite_sheet,
    pixel_shader=sprite_sheet.pixel_shader,
    width=1,
    height=1,
    tile_width=32,
    tile_height=32,
    x=0,
    y=0,
    default_tile=EMPTY_SPRITE,
)
swap_piece.hidden = True
main_group.append(swap_piece)

# Add foreground
foreground_bmp = OnDiskBitmap("/bitmaps/foreground.bmp")
foreground_bmp.pixel_shader.make_transparent(0)
foreground_tg = TileGrid(foreground_bmp, pixel_shader=foreground_bmp.pixel_shader)
foreground_tg.x = 0
foreground_tg.y = 0
main_group.append(foreground_tg)

# Add a group for the UI Elements
ui_group = Group()
main_group.append(ui_group)

# Create the mouse graphics and add to the main group
time.sleep(1)  # Allow time for USB host to initialize
mouse = find_and_init_boot_mouse("/bitmaps/mouse_cursor.bmp")
if mouse is None:
    raise RuntimeError("No mouse found connected to USB Host")
main_group.append(mouse.tilegrid)

# Create the game logic object
# pylint: disable=no-value-for-parameter, too-many-function-args
game_logic = GameLogic(
    display,
    mouse,
    game_grid,
    swap_piece,
    selected_piece_group,
    GAME_PIECES,
    HINT_TIMEOUT
)

def update_ui():
    # Update the UI elements with the current game state
    score_label.text = f"Score:\n{game_logic.score}"

waiting_for_release = False
game_over_shown = False

# Create the UI Elements
# Label for the Score
score_label = Label(
    terminalio.FONT,
    color=0xffff00,
    x=5,
    y=10,
)
ui_group.append(score_label)

message_dialog = Group()
message_dialog.hidden = True

def reset():
    global game_over_shown  # pylint: disable=global-statement
    # Reset the game logic
    game_logic.reset()
    message_dialog.hidden = True
    game_over_shown = False

def hide_group(group):
    group.hidden = True

reset()

reset_button = EventButton(
    reset,
    label="Reset",
    width=40,
    height=16,
    x=5,
    y=50,
    style=EventButton.RECT,
)
ui_group.append(reset_button)

message_label = TextBox(
    terminalio.FONT,
    text="",
    color=0x333333,
    background_color=0xEEEEEE,
    width=display.width // 3,
    height=90,
    align=TextBox.ALIGN_CENTER,
    padding_top=5,
)
message_label.anchor_point = (0, 0)
message_label.anchored_position = (
    display.width // 2 - message_label.width // 2,
    display.height // 2 - message_label.height // 2,
)
message_dialog.append(message_label)
message_button = EventButton(
    (hide_group, message_dialog),
    label="OK",
    width=40,
    height=16,
    x=display.width // 2 - 20,
    y=display.height // 2 - message_label.height // 2 + 60,
    style=EventButton.RECT,
)
message_dialog.append(message_button)
ui_group.append(message_dialog)

# main loop
while True:
    update_ui()
    # update mouse
    game_logic.update_mouse()

    if not message_dialog.hidden:
        if message_button.handle_mouse(
            (mouse.x, mouse.y),
            game_logic.pressed_btns and "left" in game_logic.pressed_btns,
            waiting_for_release
        ):
            game_logic.waiting_for_release = True
        continue

    if reset_button.handle_mouse(
        (mouse.x, mouse.y),
        game_logic.pressed_btns is not None and "left" in game_logic.pressed_btns,
        game_logic.waiting_for_release
    ):
        game_logic.waiting_for_release = True

    # process gameboard click if no menu
    game_logic.update()
    game_over = game_logic.check_for_game_over()
    if game_over and not game_over_shown:
        message_label.text = ("No more moves available. your final score is:\n"
                              + str(game_logic.score))
        message_dialog.hidden = False
        game_over_shown = True
