Digital Architecture Passive Components

Digital architecture design, simplified.

YAGEO Group Supports 98% of all passive component technologies, so to make it easier to navigate our parts, we went ahead and organized them in ways engineers actually use them. Our interactive tool is here to guide you through each stage of a digital architecture system consisting of the input stage, the switch tank converter, the DC-DC converter, the digital processor, and finally all the inputs and outputs. Each component of the system is selected to show you the latest and greatest we have to offer, all in one place. Simply click on the corresponding component, and we will provide all the details to help you make informed design decisions.

Switch Tank Converter - YAGEO XSemi Power MOSFETS

N- and P-Channel Power MOSFETS

YAGEO XSemi's semiconductor N- and P-channel MOSFET series are available in packages for surface mount applications

Input Stage - TVS Diodes

TVS Circuit Protection Components

YAGEO offers a variety of industrial and automotive grade TVS products with different package types and power ratings

Switch Tank Converter - Resonant Capacitors

U2J Dielectric High-Voltage MLCC Capacitors

KEMET's surface-mount capacitors are designed to meet the growing demand for high-AC current-resonant applications

X7R with KONNEKT™

KEMET's capacitors are designed for applications where high capacitance and voltage are needed in small board space

Switch Tank Converter - Resonant Inductors

TPI Series Large-Current Power Inductors

KEMET's TPI series ferrite core inductors are designed for a very low core loss

Switch Tank Converter - DC-Link

DC Link Capacitors

KEMET’s DC link capacitors have the benefit of high voltage, high temperature, and long life

KO-CAP® Organic Polymer Capacitors

KEMET KO-CAPs are ideal for DC-to-DC converter applications which require high capacitance, low ESR, low profile, and small footprint for hardware that seeks long life and stable performance.

Aluminum Conductive Polymer Capacitors

KEMET offers six series of single-ended and surface-mount, conductive polymer, aluminum, solid electrolytic capacitors

X7R with KONNEKT™

KEMET's capacitors are designed for applications where high capacitance and voltage are needed in small board space

Commodity Multilayer Ceramic Capacitors

YAGEO offers commodity MLCC capacitors for general purpose and high capacity applications

Input Stage / DC-DC - Inductors

MPEV Series Power Inductors

KEMET’s inductors offer a shielded construction and a surface-mount configuration

High-Current Trans-Inductors - PAL6374_HLT Series

Pulse's PAL6374_HLT is specifically designed for use with trans-inductor voltage regulator (TLVR) topology

Miniature Molded Power Inductors – BDQQ Series

Pulse's molded inductor's patented external bottom termination design offers improved efficiency and performance

Input Stage/DC-DC - Bulk Capacitors

Aluminum Conductive Polymer Capacitors

KEMET offers six series of single-ended and surface-mount, conductive polymer, aluminum, solid electrolytic capacitors

X7R with KONNEKT™

KEMET's capacitors are designed for applications where high capacitance and voltage are needed in small board space

Commodity Multilayer Ceramic Capacitors

YAGEO offers commodity MLCC capacitors for general purpose and high capacity applications

KO-CAP® Organic Polymer Capacitors

KEMET KO-CAPs are ideal for DC-to-DC converter applications which require high capacitance, low ESR, low profile, and small footprint for hardware that seeks long life and stable performance.

DC-DC - Isolation Transformers

High Isolation Power Transformers - PGT646x Series

Pulse Electronics' EFD15 platform with 4000 VRMS isolation provides versatility in DC/DC converter applications

PMS9505 Series High Isolation Current Sense Transformer

Pulse Electronics', a YAGEO Company, IATF-certified current sense transformers are designed for automotive high-performance applications

High-Isolation Gate Drive Transformer, PH9400-Series

Pulse Electronics, a YAGEO Company offers their PH9400-series of transformers which have up to 5,000 VRMS gate-to-drive isolation

DC-DC - Current Sense Resistors

Automotive Grade Current Sensor Shunt Resistor - PU Series

PU series shunt resistor is a perfect solution for applications where high precision and high power current sensing components are required.

DC-DC - Precision Voltage Resistors

RT Series - Thin Film High Precision High Stability Chip Resistor

Using advanced sputtering technology, YAGEO's thin film chip resistors provide high precision and high stability.

Digital Processor - Flex Suppressor

FLEX SUPPRESSOR® for Wi-Fi Band and 5G in Super High Frequency (SHF) Band

The KEMET FLEX SUPPRESSOR is a composite sheet that is effective for electromagnetic wave and resonance suppression

EMI FLEX SUPPRESSOR® Noise Suppression Tape - ESTX and ESTV Series

KEMET's flexible suppression tape is designed for attenuating surface conduction noise

I/O & Digital Processor - RF Capacitors

HiQ Automotive MLCC Capacitors - CBR Series

KEMET’s RF and microwave capacitors for automotive applications are lead-free and RoHS compliant

AQ Series Automotive High-Frequency MLCC

YAGEO's MLCCs are ideal for high--frequency applications such as impedance matching

I/O - Antennas

Antenna Solutions for 5G Applications

Pulse Electronics offers high-performance, compact antenna solutions for the 5G ecosystem

In-Building and Outdoor DAS Antennas

In-building and outdoor DAS antennas from Pulse Electronics, a YAGEO Company, cater to organizations and public safety entities worldwide

I/O - IPD RF Components

Ceramic X2Y® EMI Filter Capacitors

Pulse Electronics' EMI filter capacitors perform as a broadband filter enabling better EMC compliance for electrical equipment

I/O - Lan Transformers

HDBaseT™ LAN Isolation/Common Mode Filter Transformer

5Play™ enabled features from the HDBaseT technology from Pulse Electronics

Wideband Power Line Communication (PLC) SMT Transformers

Pulse Electronics’, a YAGEO Company, PLC transformers provide 4 kV isolation for wireless communication solutions

I/O - Signal Line Chokes

SMT Common-Mode Chokes

Common-mode chokes from Pulse are widely used as suppression elements against common-mode noise

Common Mode Choke 2 Line CAN-bus AEC-Q200

Pulse Electronics, a YAGEO Company introduces ChipChokes designed to suppress EMI in automotive applications

I/O - PulseJacks

Top Entry PULSEJACKS™ JXD2-0ZxxNL Series

Pulse Electronics PulseJacks meet the most stringent RoHS and WEEE directives with all traces of lead removed

10GBASE-T Integrated Connector Module

Designed to help meet tough EMC system requirements such as FCC Part 15 class B.

I/O - Connectors

SFP/SFP+ Optical Network Cages and Connectors

SFP and SFP+ connectors and cages from Pulse Electronics offer solutions for a wide variety of application

I/O - Sensors

Sensors

A growing portfolio of sensors that detect infrared thermal energy and vibration.

Resistance Temperature Detector (RTD) Sensor Assemblies

RTD sensors measure a material's electrical resistance changes with temperature

L Series Platinum Resistance Temperature Detectors (PRTD)

YAGEO Nexensos' L series platinum temperature sensors are characterized by long-term stability, excellent precision over a wide temperature range, and compatibility.

TVS Diodes

TVS Circuit Protection Components

TVS have very fast response speed to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Inductors

MPEV Series Power Inductors

MPEV series metal composite inductors are ideal for use in DC to DC switching power supplies for automotive applications.

Inductors

High-Current Trans-Inductors - PAL6374_HLT Series

The hybrid device mitigates bandwidth limitations of existing VRM solutions and further drives performance improvements.

Bulk Capacitors

Aluminum Conductive Polymer Capacitors

KEMET offers six series of single-ended and surface-mount, conductive polymer, aluminum, solid electrolytic capacitors

Bulk Capacitors

KO-CAP® Organic Polymer Capacitors

KEMET KO-CAPs are ideal for DC-to-DC converter applications which require high capacitance, low ESR, low profile, and small footprint for hardware that seeks long life and stable performance.

Bulk Capacitors

X7R with KONNEKT™

X7R with KONNEKT technology surface-mount capacitors are designed for applications where higher capacitance and voltage are needed without requiring additional board space.

Bulk Capacitors

Commodity Multilayer Ceramic Capacitors

Thanks to unique material technology, YAGEO offers many types of Multi-Layer Ceramic Capacitors (MLCC), including commodity, high capacitance, high voltage, soft-termination, X2Y and MLV (multi-layer varistor).

Resonant Capacitors

U2J Dielectric High-Voltage MLCC Capacitors

Surface-mount capacitors are designed to meet the growing demand for high-AC current-resonant applications

Resonant Capacitors

X7R with KONNEKT™

X7R with KONNEKT technology surface-mount capacitors are designed for applications where higher capacitance and voltage are needed without requiring additional board space.

Resonant Inductors

TPI Series Large-Current Power Inductors

The core material used in KEMET's TPI ferrite core inductor is ideal for high switching frequency applications. The inductor's flat wire one-turn-through-the-construction design enables high efficiency at large currents.

DC Link Capacitors

DC link capacitors have the benefit of high voltage, high temperature, and long life

DC Link Capacitors

KO-CAP® Organic Polymer Capacitors

KEMET KO-CAPs are ideal for DC-to-DC converter applications which require high capacitance, low ESR, low profile, and small footprint for hardware that seeks long life and stable performance.

DC Link Capacitors

Aluminum Conductive Polymer Capacitors

KEMET’s conductive polymer aluminum solid electrolytic capacitors (single ended/radial and surface mount) are designed for greater stability and longer life.

DC Link Capacitors

X7R with KONNEKT™

KEMET's X7R with KONNEKT technology surface-mount capacitors are designed for applications where higher capacitance and voltage are needed without requiring additional board space.

DC Link Capacitors

Commodity Multilayer Ceramic Capacitors

YAGEO XSemi Power MOSFETS

N- and P-Channel Power MOSFETS

YAGEO XSemi's semiconductor N- and P-channel MOSFET series are available in packages for surface mount applications

Inductors

MPEV Series Power Inductors

MPEV series metal composite inductors are ideal for use in DC to DC switching power supplies for automotive applications.

Inductors

Miniature Molded Power Inductors – BDQQ Series

Molded inductor's patented external bottom termination design offers improved efficiency and performance

Bulk Capacitors

Aluminum Conductive Polymer Capacitors

KEMET offers six series of single-ended and surface-mount, conductive polymer, aluminum, solid electrolytic capacitors

Bulk Capacitors

KO-CAP® Organic Polymer Capacitors

KEMET KO-CAPs are ideal for DC-to-DC converter applications which require high capacitance, low ESR, low profile, and small footprint for hardware that seeks long life and stable performance.

Bulk Capacitors

X7R with KONNEKT™

X7R with KONNEKT technology surface-mount capacitors are designed for applications where higher capacitance and voltage are needed without requiring additional board space.

Bulk Capacitors

Commodity Multilayer Ceramic Capacitors

Isolation Transformers

High Isolation Power Transformers - PGT646x Series

EFD15 platform with 4000 VRMS isolation provides versatility in DC/DC converter applications

Isolation Transformers

PMS9505 Series High Isolation Current Sense Transformer

The PMS9505 series from Pulse Electronics, a YAGEO Company, has a unique construction. The primary winding is molded into the plastic base forming a solid insulation barrier for achieving reinforced insulation properties per IEC60664/IEC60950-1 for a working voltage of up to 300 VRMS.

Isolation Transformers

High-Isolation Gate Drive Transformer, PH9400-Series

The PH9400-series is comprised of Pulse Electronics', a YAGEO Company, first ever surface-mount (SMT), high-isolation gate drive transformers.

Current Sense Resistors

Automotive Grade Current Sensor Shunt Resistor - PU Series

PU series shunt resistor is a perfect solution for applications where high precision and high power current sensing components are required.

Precision Voltage Resistors

RT Series - Thin Film High Precision High Stability Chip Resistor

Using advanced sputtering technology, YAGEO's thin film chip resistors provide high precision and high stability.

Flex Suppressor

FLEX SUPPRESSOR® for Wi-Fi Band and 5G in Super High Frequency (SHF) Band

FLEX SUPPRESSOR is a composite sheet made by blending and dispersing micron-sized magnetic material powders in a polymer base.

Flex Suppressor

EMI FLEX SUPPRESSOR® Noise Suppression Tape - ESTX and ESTV Series

KEMET, a YAGEO company's FLEX SUPPRESSOR® EMI suppression tape features polymer and blended magnetic powders that are dispersed throughout the material making it flexible to alloy when wrapping around interface cables, which helps to attenuate cable noise current and suppress radiation noise.

RF Capacitors

HiQ Automotive MLCC Capacitors - CBR Series

HiQ-CBR automotive RF capacitor series features a copper electrode BME (base metal electrode) system that offers ultra-low ESR and high Q in the VHF, UHF, and microwave frequency bands.

RF Capacitors

AQ Series Automotive High-Frequency MLCC

AQ series automotive high-frequency MLCCs can effectively reduce the power dissipation of wireless signals.

RF Capacitors

HiQ Automotive MLCC Capacitors - CBR Series

HiQ-CBR automotive RF capacitor series features a copper electrode BME (base metal electrode) system that offers ultra-low ESR and high Q in the VHF, UHF, and microwave frequency bands.

RF Capacitors

AQ Series Automotive High-Frequency MLCC

AQ series automotive high-frequency MLCCs can effectively reduce the power dissipation of wireless signals.

Antennas

Antenna Solutions for 5G Applications

Pulse Electronics offers high-performance, compact antenna solutions for the 5G ecosystem

Antennas

In-Building and Outdoor DAS Antennas

Pulse Electronics, a YAGEO Company, provides critical in-building and outdoor DAS antenna solutions worldwide to organizations and public safety entities.

IPD RF Components

Ceramic X2Y® EMI Filter Capacitors

EMI filter capacitors perform as a broadband filter enabling better EMC compliance for electrical equipment

LAN Transformers

HDBaseT™ LAN Isolation/Common Mode Filter Transformer

HDBaseT™ transformers that provide common-mode noise reduction for improved EMI performance and isolation for power over HDBaseT (PoH) applications.

LAN Transformers

Wideband Power Line Communication (PLC) SMT Transformers

PLC transformers from Pulse Electronics, a YAGEO Company, are traditionally associated with home networking and are used primarily for extending the reach of LAN connections from the central router or modem in the home office without the need to add new wiring to the building.

Signal Line Chokes

SMT Common-Mode Chokes

Common-mode chokes from Pulse are widely used as suppression elements against common-mode noise.

Signal Line Chokes

Common Mode Choke 2 Line CAN-bus AEC-Q200

Pulse Electronics, a YAGEO Company introduces ChipChokes® designed to suppress EMI in automotive applications. These products are designed to provide superior performance in automotive CANbus (Controller Area Network) networks.

PulseJacks

Top Entry PULSEJACKS™ JXD2-0ZxxNL Series

JXD2 family of top entry PulseJacks has been redesigned to comply with the most stringent RoHS and WEEE directives yet.

PulseJacks

10GBASE-T Integrated Connector Module

Pulse Electronics, a YAGEO Company introduces the 10GBASE-T (10 Gigabit over twisted-pair) integrated connector module (ICM) for servers, LAN on motherboard (LOM), adapter cards, and storage devices.

Connectors

SFP/SFP+ Optical Network Cages and Connectors

SFP and SFP+ connectors and cages from Pulse Electronics offer solutions for a wide variety of applications

Sensors

A growing portfolio of sensors that detect infrared thermal energy and vibration.

Sensors

Resistance Temperature Detector (RTD) Sensor Assemblies

RTD sensors measure a material's electrical resistance changes with temperature. YAGEO Nexensos assemblies meet the rigorous temperature sensing requirements for a wide variety of applications.

Sensors

L Series Platinum Resistance Temperature Detectors (PRTD)

YAGEO Nexensos' L series platinum temperature sensors are characterized by long-term stability, excellent precision over a wide temperature range, and compatibility.
