Thin Film Chip Resistor

RT Series - Thin Film High Precision High Stability Chip Resistor

Using advanced sputtering technology, YAGEO's thin film chip resistors provide high precision and high stability. The RT series offers case sizes from 0201 to 2512, a wide range of resistance values: 1 Ω-1.5 MΩ, narrow tolerance of ±0.01%,±0.05%, ±0.1%, ±0.25%, ±0.5%, ±1% and low TCR of ±5, ±10, ±15, ±25, ±50 ppm/°C, with power rating of 1/20 W - 3/4 W, operating temperature from –55°C to +155°C. The RT series is an excellent solution for industrial and telecommunications applications where precision and exceptional reliability characteristics are essential.

Features

  • AEC-Q200 qualified
  • High precision and stability
  • Low electrical noise
  • Narrow tolerance 0.01% and low TCR 5ppm/°C available

Specifications

  • Temperature Cycling: ±0.5%
  • Short Time Overload: ±0.5%
  • Life/Endurance: ±0.5%
  • Humidity (40°C/95% RH): ±0.5%

Applications

  • Converters
  • Industrial equipment
  • Server boards
  • Telecommunication
  • Consumer products
  • Infotainment units for automotives

Resources

Product List



Thin Film Chip Resistor

RT Series

ImageManufacturer Part NumberDescriptionPower (Watts)CompositionAvailable QuantityPriceView Details
RES SMD 10K OHM 0.1% 1/10W 0603RT0603BRD0710KLRES SMD 10K OHM 0.1% 1/10W 06030.1W, 1/10WThin Film207493 - Immediate$0.82View Details
RES SMD 20K OHM 0.1% 1/16W 0402RT0402BRD0720KLRES SMD 20K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film156159 - Immediate$0.82View Details
RES SMD 1K OHM 0.1% 1/16W 0402RT0402BRD071KLRES SMD 1K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film143965 - Immediate$0.82View Details
RES SMD 100K OHM 0.1% 1/16W 0402RT0402BRE07100KLRES SMD 100K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film138544 - Immediate$0.82View Details
RES SMD 100K OHM 0.1% 1/10W 0603RT0603BRD07100KLRES SMD 100K OHM 0.1% 1/10W 06030.1W, 1/10WThin Film138391 - Immediate$0.82View Details
RES SMD 10K OHM 0.1% 1/8W 0805RT0805BRD0710KLRES SMD 10K OHM 0.1% 1/8W 08050.125W, 1/8WThin Film46950 - Immediate$0.82View Details
RES SMD 50 OHM 0.1% 1/16W 0402RT0402BRE0750RLRES SMD 50 OHM 0.1% 1/16W 04020.063W, 1/16WThin Film41179 - Immediate$0.82View Details
RES SMD 10K OHM 0.1% 1/16W 0402RT0402BRE0710KLRES SMD 10K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film31572 - Immediate$0.82View Details
RES SMD 1K OHM 0.1% 1/16W 0402RT0402BRE071KLRES SMD 1K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film21385 - Immediate$0.82View Details
RES SMD 10K OHM 0.1% 1/16W 0402RT0402BRD0710KLRES SMD 10K OHM 0.1% 1/16W 04020.063W, 1/16WThin Film403076 - Immediate$0.99View Details
