Hirose Electric's diverse line-up of connectors for medical applications offers solutions for numerous medical devices. Choose from rectangular, high-speed I/O, RF/coaxial, mezzanine, board-to-board, wire-to-board, circular and power connectors, FPC/FFC, micro USB, coaxial switch, and Wi-Fi module connectors.

Hirose’s well-engineered connectors are highly suitable for equipment such as Portable Medical Devices, Patient Monitor Equipment, Ultrasound Scanning Systems, Ultrasound Scanning Transducers, CT Scanning Systems, MRI Systems, and other devices.

With features such as small size, easy mating-unmating, secure locking, reliable contact structures, multiple pin counts and variations, designing with Hirose connectors will provide the quality results you need.

  • Rectangular
  • Circular
  • Wire-to-Board
  • Mezzanine
  • FPC/FFC
DH Series

DH Series, High Speed I/O

  • 1 mm pitch for high-speed transmission
  • Robust design D-shaped opening
  • Secure lock with screw lock/one-touch lock
  • Applicable for high-speed data transmission
  • High-speed cable is applicable (AWG#28, Insulator outer dia.: φ0.9 ±0.04 mm max.)
  • Available in 17, 27, 37 and 51 contact positions

GT17H Series

GT17H Series, High Speed Transmission USB I/O

  • High-speed transmission capability up to 1 Gbps
  • Highly reliable lock structure
  • Shielded for EMI prevention
  • Satisfies severe automotive requirements
  • Thermal shock, 1000 cycles from -40 to +85°C
  • Heat up to 105°C
  • Single and double row

RP34 Series

RP34 Series, Low Profile Power I/O

  • Current Capacity: 5 A (for 18AWG)
  • High durability: 5000 cycles
  • Right-angle plug available
  • Two-stage sequential structure available
  • Number of terminals: 3 and 4 to position

HR30 Series

HR30 Series, Waterproof Circular I/O IP68

  • Current rating: 5 A (3 pos.) 2 A (6, 10, 12 pos.)
  • Voltage rating: 100 V AC, 140 V DC (3, 6 pos.) 30 V AC, 42 V DC (10, 12 pos.)
  • Waterproof: IP68
  • Push and pull lock, unique cable clamping method
  • Number of contact positions: 3, 6, 10 and 12 positions

LF Series

LF Series, Waterproof Circular I/O IP68

  • Number of contacts: 3, 4, 6, 11, 12, 20
  • IP68 compliant waterproof structure with shielding
  • Bayonet lock
  • Rear mount type and pin through-hole receptacles
  • Applicable cable: The size differs by the connector type

RP13A Series

RP13A Series, Push-Pull Circular I/O

  • Push-pull lock
  • Contact positions: 13, 15, 20 position
  • Rated current: 2 A Max
  • Rated voltage: AC 300 V
  • Applicable wire: AWG# 18 to 28

DF57H Series

DF57H Series, Board to Wire

  • 1.2 mm pitch, 1.4 mm height
  • 4.35 mm depth
  • Swing lock connector
  • AWG# 28-34 cable applicable
  • Insert guide key structure
  • Pin Count: 2 to 6 positions
  • 0.5 to 2.5 amp
  • UL Certified

DF59 Series

DF59 Series, Wire-to-Board with Swing Lock

  • 2.0 mm pitch
  • Multifunctional system
  • 3 Connections available: BTW, BTB joint & Short-Circuit
  • Stress free contacts (BTB)
  • Swing lock connector
  • 22 AWG
  • High current capacity, up to 3 amps
  • One common receptacle for all 3 connection types

DF61 Series

DF61 Series, Wire-to-Board with Swing Lock

  • 2.2 mm pitch, 2.38 mm height
  • BTW connector
  • 5 amp, high current capability
  • High voltage rating of 350 V
  • 22-28 AWG
  • Swing Lock Connector
  • High cable retention produced by the positive locking structure

DF12 Series

DF12 Series, Board to Board (2-Piece)

  • 0.5 mm pitch
  • 3.0 mm/3.5 mm/4.0 mm/5.0 mm stacking height
  • 4.60 mm depth
  • 0.3 AMP rated current
  • Pin Count: 10 to 80 positions

FX10 Series

FX10 Series, Board to Board High Speed Transmission

  • 0.5 mm pitch
  • Stacking height: 4 – 8 mm
  • Current rating: 0.3 A
  • Improved transmission efficiency between boards
  • Effective mating length is 1.1 mm for signal contacts
  • Contacts: w/ground plate 80, 100, 120, 140 - w/o ground plate 96, 120, 144, 168

FX11 Series

FX11 Series, Board to Board High Speed Transmission

  • 0.5 mm pitch
  • Stacking height : 2.5 mm, 3 mm
  • Effective mating length is 0.55 mm (2 mm height), 1 mm (2.5 mm, 3 mm height) for signal contacts
  • Suited to high-density applications
  • Improved transmission efficiency between boards
  • Optional ground plate
  • Pin count: 60 to 140

FH12 Series

FH12 Series, FPC/FFC

  • 0.5 mm and 1.0 mm pitch
  • Bottom contact, top contact, vertical mount available
  • Additional variations to meet users' needs
  • Wide variety of number of contact positions
  • 6 to 60 positions

FH19C Series

FH19C Series, Board to FPC (1-Piece)

  • 0.5 mm pitch, 0.9 mm height
  • Pin Count: 4 to 50 positions
  • Applicable FPC/FFC thickness: 0.2 mm ± 0.03 mm
  • FPC/FFC locking system for easy and secure lock
  • Available in SMT horizontal mounting type
  • Bottom contact

FH28 Series

FH28 Series, FPC/FFC

  • 0.5 mm pitch, 2.55 mm height
  • Rated Current: 0.5 A
  • Easy-to-use 0.3 mm thick FPC/FFC
  • Firm and clear tactile click to confirm lock completion
  • FPC tabs allow high connection reliability
  • Wide actuator opening
  • Pin Count: 10 to 80 positions
