Datasheet

Micro Commercial Components
20736 Marilla Street Chatsworth
CA 91311
Phone: (818) 701-4933
Fax: (818) 701-4939
ESD3V3D5
Thru
ESD12VD5
3.3V~12Volts
ESD Protection
SOD523
Features
• For sensitive ESD protection
• Excellent clamping capability
• Low leakage
• ESD rating of class 3(>16KV)per Human Body Mode
• For space saving application
• Fast response ,response time less than 1ns.
Maximum Ratings
• Operating Junction &StorageTemperature: -55°C to +150°C
• Maximum Thermal Resistance: 625°C/W Junction To Ambient
Parameter Symbol
Limits
unit
IEC61000-4-2(ESD) Air
Contact
±30
±30 KV
ESD Voltage per human body mode
per machine mode 16
400 KV
V
Power Dissipation Pd 200 mw
MCC
TM
Micro Commercial Components
www.mccsemi .com
1 of 3
Devices
Revision:D 2014/06/23
DIMENSIONS
INCHES MM
DIM MIN MAX MIN MAX NOTE
A .059 .067 1.50 1.70
B .043 .051 1.10 1.30
C .030 .033 0.75 0.85
D .001 .003 0.01 0.07
E .010 .014 0.25 0.35
F .003 .006 0.08 0.15
G .020 .028 0.50 0.70
H .020 .031 0.51 0.77
A
B
E
C
H
G
DF
• Epoxy meets UL 94 V-0 flammability rating
• Moisture Sensitivity Level 1
Halogen free available upon request by adding suffix "-HF"
•

ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted)
Symbol Parameter
IPP Maximum Reverse Peak Pulse Current
VC Clamping Voltage @ IPP
VRWM Working Peak Reverse Voltage
IR Maximum Reverse Leakage Current @ VRWM
VBR Breakdown Voltage @ IT
IT Test Current
IF Forward Current
VF Forward Voltage @ IF
Ppk Peak Power Dissipation
C Max. Capacitance @VR=0 and f =1MHz
ELECTRICAL CHARACTERISTICS (TA = 25°C unless otherwise noted, VF = 0.9 V Max. @ IF = 10mA for all types)
VRWM (V) IR (μA)
@ VRWM
VBR (V) @
IT(Note 2) IT
VC
@IPP+ =
5 A
IPP(A) + VC (V) @Max
IPP+ Ppk + (W) C (pF)
Device* Device
Marking
Max Max Min mA V Max Max Max Typ
ESD3V3D5 ZE 3.3 0.08 5.0 1.0 9.4 11.2 14.1 158 105
ESD5V0D5 ZF 5.0 0.08 6.2 1.0 11.6 9.4 18.6 174 80
ESD7V0D5 ZH 7.0 0.03 7.5 1.0 13.5 8.8 22.7 200 65
ESD12VD5 ZM 12 0.02 14.1 1.0 23 9.6 25 240 55
+Surge current waveform per Figure 1.
2. VBR is measured with a pulse test current IT at an ambient temperature of 25°C.
TYPICAL CHARACTERISTICS
MCC
TM
Micro Commercial Components
www.mccsemi .com
2 of 3
Revision:D 2014/06/23

MCC TM
Micro Commercial Components
www.mccsemi .com
3 of 3
Revision:D 2014/06/23
2
Device Packing
Part Number-TP Tape&Reel: 8Kpcs/Reel
Ordering Information :
***IMPORTANT NOTICE***
Micro Commercial Components Corp. reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes . Micro Commercial Components
Corp . does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold Micro Commercial Components Corp . and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited below. Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage. MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources. MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
