Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
L717SDA15PVFM | |
|---|---|
DigiKey Part Number | L717SDA15PVFM-ND |
Manufacturer | |
Manufacturer Product Number | L717SDA15PVFM |
Description | CONN D-SUB PLUG 15POS SOLDER CUP |
Manufacturer Standard Lead Time | 12 Weeks |
Customer Reference | |
Detailed Description | 15 Position D-Sub Plug, Male Pins Connector |
Datasheet | Datasheet |
EDA/CAD Models | L717SDA15PVFM Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Packaging | Tray | |
Part Status | Active | |
Connector Style | ||
Connector Type | Plug, Male Pins | |
Number of Positions | ||
Number of Rows | 2 | |
Mounting Type | ||
Shell Size, Connector Layout | 2 (DA, A) | |
Contact Type | Signal | |
Flange Feature | Mating Side, Female Screwlock (M3) | |
Termination | Solder Cup | |
Shell Material, Finish | Steel, Tin Plated | |
Contact Finish | Gold | |
Contact Finish Thickness | Flash | |
Ingress Protection | - | |
Material Flammability Rating | UL94 V-0 | |
Current Rating (Amps) | 3A | |
Backset Spacing | - | |
Features | Grounding Indents | |
Voltage Rating | 250V | |
Color | Black | |
Contact Form | Stamped | |
Dielectric Material | Thermoplastic, Glass Filled | |
Wire Gauge | 20 AWG | |
Contact Material | Brass | |
Operating Temperature | -55°C ~ 105°C | |
Base Product Number |
In-Stock: 92
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Tray
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $12.92000 | $12.92 |
| 10 | $10.99000 | $109.90 |
| 25 | $10.30000 | $257.50 |
| 50 | $9.80600 | $490.30 |
| 140 | $9.11871 | $1,276.62 |
| 280 | $8.68300 | $2,431.24 |
| 560 | $8.26830 | $4,630.25 |
| 1,120 | $7.87369 | $8,818.53 |
| 2,520 | $7.43598 | $18,738.67 |
