Make it fun to remember relative names by M5Stack for children

#include <SoftwareSerial.h>
#include <MP3Player_KT403A.h>
#include <M5EPD.h>
#include "./resources/ImageResource.h"

// edp
#define PIC_SIZE 250
#define LEFT_INDEXX  10
#define RIGHT_INDEXX  280
#define UPPER_INDEXY  50
#define MIDDLE_INDEXY  320
#define LOWER_INDEXY  590

#define BUTTON_RESET_MSEC 1000
#define DELAY_MSEC 10

int preIndex = 0;

// mp3
#define swtxPin 25
#define swrxPin 32

// Note: You must define a SoftwareSerial class object that the name must be mp3,
//       but you can change the pin number according to the actual situation.
SoftwareSerial mp3(swrxPin, swtxPin);

M5EPD_Canvas canvas(&M5.EPD);

void setup()
{
  M5.begin();
  M5.EPD.SetRotation(90);
  M5.EPD.Clear(true);

  // 写真の表示
  canvas.createCanvas(540, 960);
  canvas.setTextSize(3);
  canvas.pushImage(LEFT_INDEXX, UPPER_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_1_250x250);
  canvas.pushImage(RIGHT_INDEXX, UPPER_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_2_250x250);
  canvas.pushImage(LEFT_INDEXX, MIDDLE_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_3_250x250);
  canvas.pushImage(RIGHT_INDEXX, MIDDLE_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_4_250x250);
  canvas.pushImage(LEFT_INDEXX, LOWER_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_5_250x250);
  canvas.pushImage(RIGHT_INDEXX, LOWER_INDEXY ,PIC_SIZE,PIC_SIZE,ImageResource_6_250x250);
  canvas.pushCanvas(0,0,UPDATE_MODE_GC16);

  // タッチパネルの準備
  M5.TP.SetRotation(90);

  // mp3初期設定
  pinMode(swrxPin, INPUT);
  pinMode(swtxPin, OUTPUT);
  mp3.begin(9600);
  delay(100);
  SelectPlayerDevice(0x02);       // Select SD card as the player device.
  SetVolume(0x1E);                // Set the volume, the range is 0x00 to 0x1E.
}


// 写真番号に応じた動作
void touchAction(int picNumber){
  SpecifyMusicPlay(picNumber);
  Serial.printf("x:%d\r\n", picNumber);
}

// 領域内をタッチしたかどうか判定
bool InsideSquare(int squareIndexX, int squareIndexY, int picSize, int touchX , int touchY)
{
  if(touchX < squareIndexX) return false;
  if((squareIndexX + picSize) < touchX) return false;
  if(touchY < squareIndexY) return false;
  if((squareIndexY + picSize) < touchY) return false;

  return true;
}

// どの写真を押したかチェック
int CheckTouchPicture(int touchX , int touchY)
{
  int index = 0;

  if(InsideSquare(LEFT_INDEXX, UPPER_INDEXY ,PIC_SIZE, touchX, touchY)) index = 1;
  else if(InsideSquare(RIGHT_INDEXX, UPPER_INDEXY ,PIC_SIZE, touchX, touchY)) index = 2;
  else if(InsideSquare(LEFT_INDEXX, MIDDLE_INDEXY ,PIC_SIZE, touchX, touchY)) index = 3;
  else if(InsideSquare(RIGHT_INDEXX, MIDDLE_INDEXY ,PIC_SIZE, touchX, touchY)) index = 4;
  else if(InsideSquare(LEFT_INDEXX, LOWER_INDEXY ,PIC_SIZE, touchX, touchY)) index = 5;
  else if(InsideSquare(RIGHT_INDEXX, LOWER_INDEXY ,PIC_SIZE, touchX, touchY)) index = 6;

  return index;
}

// 0:タッチなし
// 1～6:写真をタッチ
int checkTouch(void){
  int index = 0;

  if(M5.TP.avaliable()){
    if(!M5.TP.isFingerUp()){
        M5.TP.update();
        tp_finger_t FingerItem = M5.TP.readFinger(0);
        index = CheckTouchPicture(FingerItem.x,FingerItem.y);
    }

    if(index != 0 && preIndex != index){
      preIndex = index;
      return index;
    }else{
      // 更新なし
      return 0;
    }
  }
  return 0;
}

int totalMsec;

void loop()
{
  int picIndex = checkTouch();
  if(picIndex != 0){
    touchAction(picIndex);
    totalMsec = 0;
  }

  // 押したことを初期化
  if(preIndex != 0){
    if(totalMsec < BUTTON_RESET_MSEC){
      totalMsec = totalMsec + DELAY_MSEC;
    }else{
      preIndex = 0;
      totalMsec = 0;
    }
  }else{
      preIndex = 0;
      totalMsec = 0;
  }

  delay(DELAY_MSEC);
}
