Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
VIPERGAN50TR | |
|---|---|
DigiKey Part Number | 497-VIPERGAN50TR-ND - Tape & Reel (TR) 497-VIPERGAN50TRCT-ND - Cut Tape (CT) 497-VIPERGAN50TRDKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | VIPERGAN50TR |
Description | HV CONVERTER EMBEDDING ADVANCED |
Manufacturer Standard Lead Time | 16 Weeks |
Customer Reference | |
Detailed Description | Converter Offline Flyback Topology 240kHz 15-QFN (5x6) |
Datasheet | Datasheet |
EDA/CAD Models | VIPERGAN50TR Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | STMicroelectronics | |
Series | - | |
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Output Isolation | Isolated | |
Internal Switch(s) | Yes | |
Voltage - Breakdown | 650V | |
Topology | Flyback | |
Voltage - Supply (Vcc/Vdd) | 9V ~ 23V | |
Duty Cycle | 50% | |
Frequency - Switching | 240kHz | |
Power (Watts) | 50 W | |
Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage | |
Control Features | Soft Start | |
Operating Temperature | -40°C ~ 150°C (TJ) | |
Package / Case | 15-VQFN Exposed Pad | |
Supplier Device Package | 15-QFN (5x6) | |
Mounting Type | Surface Mount | |
Base Product Number |
In-Stock: 4,000
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $25.29000 | $25.29 |
| 10 | $18.95900 | $189.59 |
| 25 | $17.37440 | $434.36 |
| 100 | $15.62800 | $1,562.80 |
| 250 | $14.79492 | $3,698.73 |
| 500 | $14.29322 | $7,146.61 |
| 1,000 | $13.87996 | $13,879.96 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 4,000 | $13.26009 | $53,040.36 |
