Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
TS18-5-15-SL-160-SMT-TR | |
|---|---|
DigiKey Part Number | 2223-TS18-5-15-SL-160-SMT-TR-ND - Tape & Reel (TR) 2223-TS18-5-15-SL-160-SMT-TRCT-ND - Cut Tape (CT) 2223-TS18-5-15-SL-160-SMT-TRDKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | TS18-5-15-SL-160-SMT-TR |
Description | SWITCH TACTILE SPST-NO 0.05A 12V |
Manufacturer Standard Lead Time | 12 Weeks |
Customer Reference | |
Detailed Description | Tactile Switch SPST-NO Top Actuated Surface Mount |
Datasheet | Datasheet |
EDA/CAD Models | TS18-5-15-SL-160-SMT-TR Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Circuit | SPST-NO | |
Switch Function | Off-Mom | |
Contact Rating @ Voltage | 0.05A @ 12VDC | |
Actuator Type | Standard | |
Mounting Type | ||
Actuator Height off PCB, Vertical | 1.50mm | |
Actuator Length, Right Angle | - | |
Actuator Orientation | Top Actuated | |
Termination Style | Gull Wing | |
Outline | 5.20mm x 5.20mm | |
Illumination | Non-Illuminated | |
Illumination Type, Color | - | |
Illumination Voltage (Nominal) | - | |
Operating Force | 160gf | |
Ingress Protection | - | |
Features | - | |
Operating Temperature | -30°C ~ 80°C | |
Actuator Material | Brass, Nickel Plated | |
Switch Travel | 0.20mm | |
Mechanical Life | 80,000 Cycles | |
Base Product Number |
In-Stock: 1,181
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $1.55000 | $1.55 |
| 10 | $1.34600 | $13.46 |
| 25 | $1.26600 | $31.65 |
| 100 | $1.13810 | $113.81 |
| 250 | $1.05572 | $263.93 |
| 500 | $0.99632 | $498.16 |
| 1,000 | $0.94035 | $940.35 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 4,000 | $0.84012 | $3,360.48 |
| 8,000 | $0.79651 | $6,372.08 |
| 12,000 | $0.77307 | $9,276.84 |
| 20,000 | $0.74566 | $14,913.20 |
| 28,000 | $0.72887 | $20,408.36 |
| 40,000 | $0.71215 | $28,486.00 |
| 100,000 | $0.67399 | $67,399.00 |
