AHDP02-24-07PN-WTACL22 is out of stock and can be placed on backorder.
Available Substitutes:
Parametric Equivalent
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
AHDP02-24-07PN-WTACL22 | |
|---|---|
DigiKey Part Number | 889-AHDP02-24-07PN-WTACL22-ND |
Manufacturer | |
Manufacturer Product Number | AHDP02-24-07PN-WTACL22 |
Description | 7 POSITION PANEL MOUNT RECEPTACL |
Manufacturer Standard Lead Time | 14 Weeks |
Customer Reference | |
Detailed Description | 7 Position Circular Connector Receptacle Housing Panel Mount |
Datasheet | Datasheet |
EDA/CAD Models | AHDP02-24-07PN-WTACL22 Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | Amphenol Sine Systems Corp | |
Series | ||
Packaging | Box | |
Part Status | Active | |
Connector Type | Receptacle Housing | |
Type | For Male Pins | |
Number of Positions | 7 | |
Shell Size - Insert | 24-7 | |
Shell Size, MIL | - | |
Contact Type | Crimp | |
Contact Size | 4 (3), 16 (4) | |
Mounting Type | Panel Mount | |
Mounting Feature | Flange | |
Fastening Type | Bayonet Lock | |
Orientation | Keyed | |
Primary Material | Plastic | |
Shell Material | Thermoplastic | |
Shell Finish | - | |
Housing Color | Black | |
Ingress Protection | IP67/IP69K - Dust Tight, Water Resistant, Waterproof | |
Material Flammability Rating | - | |
Features | - | |
Shielding | Unshielded | |
Note | Contacts Not Included | |
Includes | - | |
Insert Material | Thermoplastic | |
Contact Shape | Circular | |
Operating Temperature | -55°C ~ 125°C | |
Base Product Number |
0 In Stock
Check Lead Time
Request Stock Notification
Quantity
All prices are in HKD
Box
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $145.95000 | $145.95 |
| 10 | $124.06400 | $1,240.64 |
| 25 | $116.29200 | $2,907.30 |
| 50 | $110.74180 | $5,537.09 |
| 100 | $105.45850 | $10,545.85 |
| 250 | $98.86104 | $24,715.26 |
| 500 | $94.14872 | $47,074.36 |
