Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ACS37042KLHBLT-030B5 | |
|---|---|
DigiKey Part Number | 620-ACS37042KLHBLT-030B5TR-ND - Tape & Reel (TR) 620-ACS37042KLHBLT-030B5CT-ND - Cut Tape (CT) 620-ACS37042KLHBLT-030B5DKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | ACS37042KLHBLT-030B5 |
Description | ISOLATED CURRENT SENSOR |
Manufacturer Standard Lead Time | 16 Weeks |
Customer Reference | |
Detailed Description | Current Sensor ±30A 1 Channel Hall Effect Bidirectional SOT-23W |
Datasheet | Datasheet |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
For Measuring | DC | |
Sensor Type | ||
Current - Sensing | ||
Number of Channels | 1 | |
Output | Analog Voltage | |
Sensitivity | 66.7mV/A | |
Frequency | DC ~ 125kHz | |
Linearity | - | |
Accuracy | - | |
Voltage - Supply | 4.5V ~ 5.5V | |
Response Time | 5µs | |
Current - Supply (Max) | 12mA | |
Operating Temperature | -40°C ~ 125°C | |
Grade | Automotive | |
Qualification | AEC-Q100 | |
Polarization | Bidirectional | |
Mounting Type | ||
Package / Case | SOT-23W | |
Supplier Device Package | SOT-23W |
In-Stock: 2,972
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $9.71000 | $9.71 |
| 5 | $8.59400 | $42.97 |
| 10 | $8.17400 | $81.74 |
| 25 | $7.66560 | $191.64 |
| 50 | $7.31820 | $365.91 |
| 100 | $7.00050 | $700.05 |
| 500 | $6.36300 | $3,181.50 |
| 1,000 | $6.12609 | $6,126.09 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 3,000 | $5.67440 | $17,023.20 |
| 6,000 | $5.48884 | $32,933.04 |
| 9,000 | $5.38751 | $48,487.59 |
| 15,000 | $5.26690 | $79,003.50 |
