2.4/5 GHz Antenna
Wireless Series

2.4/5 GHz Antenna

YAGEO's antennas for Bluetooth, IEEE802.11 devices, 2.4 GHz and 2.4/5 GHz standards are widely used on computers, laptops, tablets, mobile phones, and other portable devices for Wireless Components personal area networks.

Features

  • Compact size
  • Omni-directional radiation
  • Dual-band design
  • Tape & reel automatic mounting
  • Reflow process compatible

Specifications

  • Frequency: 2.4/2.45 GHz & 5 GHz
  • Linear polarization
  • Impedance: 50 Ω
  • Maximum Power : 1 W
  • Operating temperature: -40°C ~ +105°C

Applications

  • 2.4 & 5 GHz WiFi device
  • ISM band equipment
  • Bluetooth gadget
  • ZigBee device

Product List



Wireless Series

Wireless Components 2-5 GHz Antenna

ImageManufacturer Part NumberDescriptionFrequency (Center/Band)Frequency RangeAvailable QuantityPriceView Details
RF ANT 5.3685GHZ PCB TRACE CABANTX100P001B50003RF ANT 5.3685GHZ PCB TRACE CAB5.3685GHz5.15GHz ~ 5.875GHz0 - ImmediateSee Page for PricingView Details
RF ANT 5.3685GHZ PCB TRACE CABANTX100P011B50003RF ANT 5.3685GHZ PCB TRACE CAB5.3685GHz5.15GHz ~ 5.875GHz0 - ImmediateSee Page for PricingView Details
RF ANT 2.45/5.5125GHZ FLAT PATCHANTX100P111B24553RF ANT 2.45/5.5125GHZ FLAT PATCH2.45GHz, 5.5125GHz2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.875GHz252 - Immediate$14.32View Details
RF ANT 2.45/5.5125GHZ FLAT PATCHANTX100P112B24553RF ANT 2.45/5.5125GHZ FLAT PATCH2.45GHz, 5.5125GHz2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.875GHz1883 - Immediate$25.19View Details
RF ANT 2.45GHZ PCB TRACE CAB ADHANTX100P113B24003RF ANT 2.45GHZ PCB TRACE CAB ADH2.45GHz2.4GHz ~ 2.5GHz2840 - Immediate$18.52View Details
RF ANT 2.45GHZ CER PATCH SLDRANT1212B00BT2400SRF ANT 2.45GHZ CER PATCH SLDR2.45GHz2.4GHz ~ 2.5GHz0 - Immediate$23.54View Details
RF ANT 2.442GHZ CHIP SOLDER SMDANT1005LL14R2400ARF ANT 2.442GHZ CHIP SOLDER SMD2.442GHz2.4GHz ~ 2.484GHz27253 - Immediate$1.23View Details
RF ANT 2.45GHZ CHIP SOLDER SMDANT1608LL14R2400ARF ANT 2.45GHZ CHIP SOLDER SMD2.45GHz2.4GHz ~ 2.5GHz20485 - Immediate$2.14View Details
RF ANT 2.45GHZ/5.5GHZ CHIP SLDANT1608LL14R2455ARF ANT 2.45GHZ/5.5GHZ CHIP SLD2.45GHz, 5.5GHz-20038 - Immediate$1.81View Details
RF ANT 2.45GHZ CHIP SOLDER SMDANT2012LL00R2400ARF ANT 2.45GHZ CHIP SOLDER SMD2.45GHz2.4GHz ~ 2.5GHz13885 - Immediate$3.79View Details
RF ANT 2.45GHZ CHIP SOLDER SMDANT3216LL00R2400ARF ANT 2.45GHZ CHIP SOLDER SMD2.45GHz2.4GHz ~ 2.5GHz21408 - Immediate$3.62View Details
RF ANT 2.45GHZ CER PATCH SLDRANT3216LL11R2400ARF ANT 2.45GHZ CER PATCH SLDR2.45GHz2.4GHz ~ 2.5GHz1076 - Immediate$2.96View Details
RF ANT 2.45GHZ CHIP SOLDER SMDANT7836LL15R2400ARF ANT 2.45GHZ CHIP SOLDER SMD2.45GHz2.4GHz ~ 2.5GHz8164 - Immediate$11.69View Details
RF ANT 2.45GHZ CHIP SOLDER SMDANT9520LL06R2400ARF ANT 2.45GHZ CHIP SOLDER SMD2.45GHz2.4GHz ~ 2.5GHz0 - Immediate$9.96View Details
