RV Series
Thick Film Chip Resistors

High Voltage Chip Resistors - RV Series

YAGEO's high voltage series is ideal for industrial automation, power supplies, and battery chargers. The series is designed to handle a maximum working voltage of 500 V with case sizes from 0603 to 2512. The surface mountable resistors are suitable for handling by automatic placement systems.

RV0603 (100 KΩ to 10 MΩ), RV0805 (100 KΩ to 22 MΩ), RV1206 (100 K to 27 MΩ) have obtained IEC 62368-1:2014 (section G.10.2) safety certificate issued by UL.

Features

  • Higher max. working voltage
  • Provide safety and reliability in discharge, balancing
  • Good stability of resistivity in the high voltage circuit
  • Designing for compliance to IEC 60065

Specifications

  • Case size: 0603 - 2512
  • Tolerance: ±0.5%, ±1%, ±5%
  • TCR: ±200 ppm/°C
  • Resistance: 47 Ω to 27 MΩ

Applications

  • Power supply
  • LED lighting
  • Industrial
  • Battery, Charger

Resources

Product List



Thick Film Chip Resistors

RV Series

ImageManufacturer Part NumberDescriptionResistanceTolerancePower (Watts)Available QuantityView Details
RES SMD 22M OHM 5% 1/4W 1206RV1206JR-0722MLRES SMD 22M OHM 5% 1/4W 120622 MOhms±5%0.25W, 1/4W511586 - ImmediateView Details
RES SMD 27M OHM 5% 1/4W 1206RV1206JR-0727MLRES SMD 27M OHM 5% 1/4W 120627 MOhms±5%0.25W, 1/4W21831 - ImmediateView Details
RES SMD 10M OHM 5% 1/4W 1206RV1206JR-0710MLRES SMD 10M OHM 5% 1/4W 120610 MOhms±5%0.25W, 1/4W17452 - ImmediateView Details
RES SMD 470K OHM 5% 1/4W 1206RV1206JR-07470KLRES SMD 470K OHM 5% 1/4W 1206470 kOhms±5%0.25W, 1/4W10207 - ImmediateView Details
RES SMD 1M OHM 5% 1/4W 1206RV1206JR-071MLRES SMD 1M OHM 5% 1/4W 12061 MOhms±5%0.25W, 1/4W19115 - ImmediateView Details
RES SMD 1M OHM 1% 1/4W 1206RV1206FR-071MLRES SMD 1M OHM 1% 1/4W 12061 MOhms±1%0.25W, 1/4W6165 - ImmediateView Details
RES 11 MOHM 1% 1/4W 1206RV1206FR-0711MLRES 11 MOHM 1% 1/4W 120611 MOhms±1%0.25W, 1/4W4976 - ImmediateView Details
RES SMD 2.7M OHM 5% 1/4W 1206RV1206JR-072M7LRES SMD 2.7M OHM 5% 1/4W 12062.7 MOhms±5%0.25W, 1/4W9500 - ImmediateView Details
RES SMD 3.3M OHM 5% 1/4W 1206RV1206JR-073M3LRES SMD 3.3M OHM 5% 1/4W 12063.3 MOhms±5%0.25W, 1/4W9360 - ImmediateView Details
RES SMD 2.2M OHM 5% 1/4W 1206RV1206JR-072M2LRES SMD 2.2M OHM 5% 1/4W 12062.2 MOhms±5%0.25W, 1/4W9343 - ImmediateView Details
