Keep it simple! Sense with MEMS.

Würth Elektronik MEMS Sensor Portfolio

The Würth Elektronik sensors are an integral part of every future application. Measuring temperature, humidity, pressure or acceleration has never been easier. Take advantage of services like the Software Development Kit and Evaluation Boards available off-the-shelf. Detailed documentations as well as the direct support by trained engineers will leave no questions open.

With excellent measuring accuracy and long-term stability, the sensors provide high precision and accurate output values with intelligent on-chip interrupt functions.

Combine sensors and wireless connectivity - start your IoT application today!

Product Benefits

  • Support by engineers within 24 h
  • Excellent measuring accuracy
  • Factory calibrated & ready to use
  • On-chip interrupt functions
  • Implemented algorithms
  • SPI & I²C digital interfaces

6 Axis Inertial Measurement Unit (IMU) - WSEN-ISDS

  • MEMS based capacitive sensing principle
  • Fully calibrated 16 bit output
  • Acceleration full scale: ±2 g, ±4 g, ±8 g, ±16 g
  • Gyroscope full scale: ±125 dps, ±250 dps, ±500 dps, ±1000 dps, ±2000 dps
  • Output data rate: 6.6 kHz
  • I2C and SPI digital communication interface

3-Axis Acceleration Sensor – WSEN-ITDS

  • Temperature range: -40°C up to +85°C
  • I²C and SPI digital communication interface
  • 14-bit output resolution
  • Bandwidth up to 1,600 Hz
  • Embedded temperature sensor

Temperature Sensor IC – WSEN-TIDS

  • -40°C to +125°C measurement range
  • Digital I²C communication interface
  • 16 bits temperature output resolution
  • Selectable output data rate up to 200 Hz

Humidity Sensor – WSEN-HIDS

  • 0 to 100 % rH measurement range with an integrated temperature sensor
  • I²C and SPI communication interface
  • 16 bit humidity and temperature output resolution
  • Selectable output data rate up to 12.5 Hz
  • Calibrated humidity and temperature output values

Differential Pressure Sensor – WSEN-PDUS

  • Wide measurement range from ±0.1 kPa to 1 MPa
  • I²C and analog communication interface
  • Amplified, calibrated and temperature compensated output signal
  • 15 bit digital and 11 bit analog pressure output resolution
  • Evaluation board including mounted adapter

Absolute Pressure Sensor – WSEN-PADS

  • 26 to 126 kPa pressure range with integrated temperature sensor
  • I²C and SPI communication interface
  • 24 bit pressure output resolution
  • Selectable output data rate up to 200 Hz
  • 128 level FIFO buffer

Resources
