MCOIL™ Series
TAIYO YUDEN's best-in-class DC bias characteristics with superior materials and process technology
TAIYO YUDEN has recently expanded their award-winning MCOIL™ metal power inductor line with several new series, including two series, which include AEC-Q200 qualified versions. MCOIL's metallic magnetic materials are optimized for use in choke coils. Target applications include power supply circuits in mobile, automotive, and industrial markets, among others. These applications require components that deliver a high current in a compact space. The combination of newly developed metallic magnetic materials along with TAIYO YUDEN’s advanced process technology achieves the industry’s best-in-class DC bias characteristics. This coupled with size reduction and higher current capability offers application engineers one of the best values available today.
MCOIL White Paper: Material Advances Enable New Generation of Power Inductors
| Applications for the MCOIL™ include: | |
|
|
| MA Series | MB Series | |
| Metal core wire-wound chip power inductors | Low cost metal core wire-wound chip power inductors | |
|
MA-H Series High specification metal core wire-wound chip inductors for anti-noise applications in power circuits ME Series Metal core, wire-wound chip power inductors feature low-loss, low RDC, and excellent DC bias characteristics for anti-noise applications |
MD Series High current square metal core SMD power inductors |
| *Available in a variety of inductances and tolerances Available in standard and AEC-Q200 Qualified series † Automotive grade part numbers denoted by a "V" ending |
MA and MA-H Series
| Image | Manufacturer Part Number | Description | Inductance | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|
 |  | MAMK2520T1R0M | FIXED IND 1UH 2.7A 59 MOHM SMD | 1 µH | 110190 - Immediate | $1.32 | View Details |
| | MAMK2520T2R2M | FIXED IND 2.2UH 1.9A 117MOHM SMD | 2.2 µH | 18319 - Immediate | $1.32 | View Details |
| | MAMK2520T3R3M | FIXED IND 3.3UH 1.7A 156MOHM SMD | 3.3 µH | 113175 - Immediate | $1.23 | View Details |
| | MAMK2520T4R7M | FIXED IND 4.7UH 1.3A 260MOHM SMD | 4.7 µH | 371893 - Immediate | $1.32 | View Details |
| | MAMK2520TR47M | FIXED IND 470NH 3.4A 39 MOHM SMD | 470 nH | 29197 - Immediate | $1.32 | View Details |
| | MAKK2016T1R5M | FIXED IND 1.5UH 1.65A 130MOHM SM | 1.5 µH | 1789 - Immediate | $1.23 | View Details |
| | MAKK2016TR24M | FIXED IND 240NH 3A 42 MOHM SMD | 240 nH | 0 - Immediate | $1.56 | View Details |
| | MAKK2016TR47M | FIXED IND 470NH 2.8A 460MOHM SMD | 470 nH | 291 - Immediate | $1.23 | View Details |
| | MAKK2016TR68M | FIXED IND 680NH 2.5A 65 MOHM SMD | 680 nH | 7678 - Immediate | $1.23 | View Details |
| | MAKK2520T1R0M | FIXED IND 1UH 2.5A 72 MOHM SMD | 1 µH | 4599 - Immediate | $1.32 | View Details |
MB and MB-H Series
| Image | Manufacturer Part Number | Description | Inductance | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|
|  | MBKK1608T1R0M | FIXED IND 1UH 1.15A 150 MOHM SMD | 1 µH | 10499 - Immediate | $1.23 | View Details |
| | MBKK1608T1R5M | FIXED IND 1.5UH 1A 200 MOHM SMD | 1.5 µH | 67692 - Immediate | $1.23 | View Details |
| | MBKK1608T2R2M | FIXED IND 2.2UH 750MA 345MOHM SM | 2.2 µH | 39447 - Immediate | $1.15 | View Details |
| | MBKK1608T3R3M | FIXED IND 3.3UH 600MA 512MOHM SM | 3.3 µH | 5136 - Immediate | $1.23 | View Details |
| | MBKK1608T4R7M | FIXED IND 4.7UH 500MA 730MOHM SM | 4.7 µH | 172642 - Immediate | $1.23 | View Details |
| | MBKK1608TR24N | FIXED IND 240NH 2.3A 49 MOHM SMD | 240 nH | 7526 - Immediate | $1.23 | View Details |
| | MBKK1608TR47N | FIXED IND 470NH 1.4A 104MOHM SMD | 470 nH | 8331 - Immediate | $1.23 | View Details |
| | MBKK1608TR68N | FIXED IND 680NH 1.2A 120MOHM SMD | 680 nH | 5810 - Immediate | $1.23 | View Details |
| | MBKK2012T1R0M | FIXED IND 1UH 1.45A 106 MOHM SMD | 1 µH | 168965 - Immediate | $1.23 | View Details |
| | MBKK2012T1R5M | FIXED IND 1.5UH 1.1A 173MOHM SMD | 1.5 µH | 181 - Immediate | $2.06 | View Details |
MD Series
| Image | Manufacturer Part Number | Description | Available Quantity | Price | ||
|---|---|---|---|---|---|---|
|  | MDMK2020T3R3MM | FIXED IND 3.3UH 1.15A 178MOHM SM | 18723 - Immediate | $2.39 | View Details |
|  | MDKK3030T2R2MM | FIXED IND 2.2UH 1.9A 144MOHM SMD | 3266 - Immediate | $3.13 | View Details |
|  | MDWK4040T2R2MM | FIXED IND 2.2UH 3.5A 54 MOHM SMD | 6177 - Immediate | $3.79 | View Details |
| | MDWK4040T3R3MM | FIXED IND 3.3UH 3A 75 MOHM SMD | 5624 - Immediate | $3.79 | View Details |
| | MDWK4040T4R7MM | FIXED IND 4.7UH 2.5A 107MOHM SMD | 3046 - Immediate | $3.79 | View Details |
| | MDWK4040T1R0MM | FIXED IND 1UH 5.1A 27 MOHM SMD | 2647 - Immediate | $3.79 | View Details |
| | MDMK2020T1R0MM | FIXED IND 1UH 1.9A 64 MOHM SMD | 6074 - Immediate | $2.39 | View Details |
|  | MDKK1616T150MM | FIXED IND 15UH 400MA 1.8 OHM SMD | 4729 - Immediate | $2.39 | View Details |
| | MDKK1616T100MM | FIXED IND 10UH 450MA 1.12OHM SMD | 4226 - Immediate | $2.39 | View Details |
| | MDKK1616T6R8MM | FIXED IND 6.8UH 520MA 820MOHM SM | 1002 - Immediate | $2.39 | View Details |
ME Series
| Image | Manufacturer Part Number | Description | Inductance | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|---|
|  | MEKK2016TR47M | FIXED IND 470NH 4.3A 30 MOHM SMD | 470 nH | 12340 - Immediate | $2.72 | View Details |
| | MEKK2016T1R0M | FIXED IND 1UH 3.1A 60 MOHM SMD | 1 µH | 8709 - Immediate | $2.72 | View Details |
| | MEKK2016T2R2M | FIXED IND 2.2UH 1.9A 150MOHM SMD | 2.2 µH | 0 - Immediate | $2.72 | View Details |
| | MEKK2520TR47M | FIXED IND 470NH 4.8A 25 MOHM SMD | 470 nH | 4864 - Immediate | $2.72 | View Details |
| | MEKK2520T1R0M | FIXED IND 1UH 3.3A 53 MOHM SMD | 1 µH | 6011 - Immediate | $2.72 | View Details |
| | MEKK2520TR33M | FIXED IND 330NH 5.1A 22 MOHM SMD | 330 nH | 0 - Immediate | $2.72 | View Details |
| | MEKK2520T2R2M | FIXED IND 2.2UH 2.4A 97 MOHM SMD | 2.2 µH | 3818 - Immediate | $2.72 | View Details |
| | MEKK2520T4R7M | FIXED IND 4.7UH SMD | 4.7 µH | 7173 - Immediate | $2.72 | View Details |
| | MEKK2016HR47M | FIXED IND 470NH 4.7A 26 MOHM SMD | 470 nH | 3260 - Immediate | $2.06 | View Details |
| | MEKK2016H1R0M | FIXED IND 1UH 3.5A 48 MOHM SMD | 1 µH | 40744 - Immediate | $2.06 | View Details |
|  | MEKK2016H2R2M | FIXED IND 2.2UH 2.3A 100MOHM SMD | 2.2 µH | 0 - Immediate | $2.06 | View Details |
| | MEKK2016TR68M | FIXED IND 680NH 3.3A 52 MOHM SMD | 680 nH | 901 - Immediate | $1.89 | View Details |
| | MEKK2520T1R5M | FIXED IND 1.5UH 2.8A 69 MOHM SMD | 1.5 µH | 2735 - Immediate | $2.06 | View Details |
| | MEKK2520T3R3M | FIXED IND 3.3UH 1.8A 144MOHM SMD | 3.3 µH | 1633 - Immediate | $2.06 | View Details |
