PowerSPIN™ Smart Monolithic Motor Control ICs

Integrated PWM controller and DMOS bridge for brush DC, bipolar stepper and permanent-magnet 3-phase brushless motors, offering non-dissipative overcurrent detection.

Overview
L2293Q
L6219
L6219R
L6205
L6225
L6206
L6226
L6207
L6227
L6208
L6228
L6235
L6229
L6230

PowerSPIN: DC Motor Driver ICs

The PowerSPIN series includes a complete set of dual H-bridge drivers for DC and stepper motors. All devices integrate a power stage array and gate drivers in a single chip, with benefits in terms of footprint and cost reduction. There are two options for the power stage, one with a current capability of 2.8 A (L620x family) and the other 1.4 A (L622x family). Both are available in four packages (SO, PowerSO, DIP and the more compact QFN) to meet all assembly and power handling requirements.

The robustness of motor control architectures based on PowerSPIN devices is ensured by a complete set of protection features embedded in each driver. These include cross conduction protection, thermal shutdown, undervoltage lock out and non-dissipative overcurrent protection (which eliminates the need for an external shunt resistor). PowerSPIN devices are supported with the practiSPIN ecosystem that allows real-time evaluation of the entire motion control system, including first-cut thermal analysis. The ecosystem consists of an EVAL62xx demo board, specific for each driver, the EVALPRACTISPIN interface board and the PRACTISPIN software.

Key benefits of PowerSPIN:

Integrated PWM controller and DMOS bridge for brush DC, bipolar stepper and permanent-magnet 3-phase brushless motors, offering non-dissipative overcurrent detection
Complete set of dual H-bridge drivers so you may simultaneously drive two single-phase BLDC motors or, paralleling the outputs of the power stages, drive a single motor with a higher current rating
Integrated power stage array and gate drivers
Conduction protection, thermal shutdown, undervoltage lock out and non-dissipative overcurrent protection (which eliminates the need for an external shunt resistor)
practiSPIN ecosystem allows real-time evaluation of the entire motion-control system, including first-cut thermal analysis
Wide voltage and current rating

PowerSPIN: Push-pull four channel driver with diodes

Part Number	Current Output	Voltage Load	Operating Temp	Package
L2293Q	600mA	-	-20°C ~ 125°C	32-VFQFN	Learn More

Development Kits
EVAL2293Q	BOARD DEMO FOR L2293Q 4CH DRIVER	Learn More

Features: L2293Q

600 mA output current capability per channel
1.2 A peak output current (non repetitive) per channel
Enable facility
Overtemperature protection

Logical "0" input voltage up to 1.5 V (high noise immunity)
Internal clamp diodes

PowerSPIN: Stepper Motor Driver

Part Number	Current Output	Voltage Load	Operating Temp	Package
L6219R	±500mA	4.5 V ~ 10 V	-20°C ~ 85°C	24-SOIC	Learn More
E-L6219R	±500mA	4.5 V ~ 10 V	-20°C ~ 85°C	24-SOIC	Learn More
E-L6219DS	750mA	10 V ~ 46 V	-40°C ~ 125°C	24-SOIC	Learn More
E-L6219	±750	10 V ~ 46 V	-20°C ~ 85°C	24-DIP	Learn More

Features: L6219/L6219R

Able to drive both windings of bipolar stepper motor
Output current up to 500mA each winding
Wide voltage range 4.5V to 10V
HAlf-step, full-step and microstepp-ing mode
Built-in protection diodes

Internal pwm current control
Low output saturation voltage
Designed for unstabilized motor supply voltage
Internal thermal shutdown

PowerSPIN: Dual DMOS Full Bridge Driver

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6205D	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6205PD	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6205N	300 mOhm	2.8A	5.6A	PowerDIP-20	Learn More
L6225D	730 mOhm	1.4A	2.8A	20-SOIC	Learn More
L6225PD	730 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6225N	730 mOhm	2.8A	5.6A	PowerDIP-20	Learn More

Development Kits
EVAL6206N	EVAL BOARD FOR L6206N DIP	Learn More
EVAL6205N	EVAL BOARD FOR L6205N DIP	Learn More
EVAL6225PD	EVAL BOARD FOR L6225PD SOIC	Learn More

Features: L6205/L6225

7 to 52 V_DC operating voltage
Low R_{DS(on)
0.3Ω typ L620x series
0.7Ω typ L622x series}
Output current:
- 2.8 A_DC (5.6 A peak) L620x series
- 1.4 A_DC (2.8 A peak) L622x series
Operating frequency up to 100 kHz

Full set of protection features:
- Non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, SO, DIP

PowerSPIN: Dual DMOS Full Bridge Driver with Diagnostic

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6206D	300 mOhm	2.8A	5.6A	24-SOIC	Learn More
L6206N	300 mOhm	2.8A	5.6A	24-PowerDIP	Learn More
L6206PD	300 mOhm	2.8A	5.6A	PowerSO-36	Learn More
L6206Q	340 mOhm	1.4A	2.8A	48-QFN (7x7)	Learn More
L6226D	730 mOhm	1.4A	2.8A	24-SOIC	Learn More
L6226N	730 mOhm	1.4A	2.8A	24-PowerDIP	Learn More
L6226PD	730 mOhm	1.4A	2.8A	PowerSO-36	Learn More
L6226Q	730 mOhm	1.4A	2.8A	32-VFQFPN	Learn More

Development Kits
EVAL6206PD	EVAL BOARD FOR L6206 SERIES	Learn More
EVAL6206Q	BOARD DEMO L6206Q BRIDGE DIODE	Learn More
EVAL6206N	EVAL BOARD FOR L6206N DIP	Learn More
EVAL6226QR	EVAL BOARD FOR L6226Q	Learn More

Features: L6206/L6226

7 to 52 V_DC operating voltage
Low R_{DS(on)
0.3Ω typ L620x series
0.7Ω typ L622x series}
Output current:
- 2.8 A_DC (5.6 A peak) L620x series
- 1.4 A_DC (2.8 A peak) L622x series
Operating frequency up to 100 kHz

Full set of protection features:
- Programmable non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, SO, DIP, QFN

PowerSPIN: Dual DMOS Full Bridge Driver with PWM Current Controller

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6207D	340 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6207N	300 mOhm	2.8A	5.6A	24-PowerDIP	Learn More
L6207PD	300 mOhm	2.8A	5.6A	PowerSO-36	Learn More
L6207Q	300 mOhm	2.5A	5.6A	48-VFQFPN (7x7)	Learn More
L6227D	730 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6227N	730 mOhm	2.8A	5.6A	24-SOIC	Learn More
L6227PD	730 mOhm	2.8A	5.6A	PowerSO-36	Learn More
L6227Q	730 mOhm	2.8A	5.6A	32-VFQFPN	Learn More

Development Kits
EVAL6207N	BOARD MOTOR STEPPER/DC L6207 DIP	Learn More
EVAL6227QR	EVAL BOARD FOR L6227Q	Learn More
EVAL6227PD	EVAL BOARD FOR L6227PD SOIC	Learn More

Features: L6207/L6227

7 to 52 V_DC operating voltage
Low R_{DS(on)
0.3Ω typ L620x series
0.7Ω typ L622x series}
Output current:
- 2.8 A_DC (5.6 A peak) L620x series
- 1.4 A_DC (2.8 A peak) L622x series
Operating frequency up to 100 kHz

Twin integrated PWM (current control)
Full set of protection features:
- Non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, SO, DIP, QFN

PowerSPIN: Fully Integrated Stepper Motor Driver

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6208D	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6208N	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6208PD	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6208Q	300 mOhm	2.8A	5.6A	PowerDIP-20	Learn More
L6228D	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6228N	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6228PD	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6228Q	300 mOhm	2.8A	5.6A	PowerDIP-20	Learn More

Development Kits
EVAL6208PD	EVAL BOARD FOR L6208 SERIES	Learn More
EVAL6208N	EVAL BOARD FOR L6208N DIP	Learn More
EVAL6208Q	BOARD DEMO L6208Q MOTOR DRIVER	Learn More
EVAL6228QR	EVAL BOARD FOR L6228Q	Learn More

Features: L6208/L6228

7 to 52 V_DC operating voltage
Low R_{DS(on)
0.3Ω typ L620x series
0.7Ω typ L622x series}
Output current:
- 2.8 A_DC (5.6 A peak) L620x series
- 1.4 A_DC (2.8 A peak) L622x series
Operating frequency up to 100 kHz

Integrated stepping sequence generator
Twin integrated PWM (current control)
Full set of protection features:
- Programmable non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, SO, DIP, QFN

PowerSPIN: Three Phase Brushless DC Motor Driver

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6235D	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6235N	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6235PD	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6235Q	300 mOhm	2.8A	5.6A	PowerDIP-20	Learn More
L6229D	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6229N	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6229PD	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More
L6229Q	300 mOhm	2.8A	5.6A	PowerDIP-20	Learn More

Development Kits
EVAL6235N	BOARD MOTOR BRUSHLESS DC L6235	Learn More
EVAL6235Q	BOARD DEMO L6235Q MOTOR DRIVER	Learn More
EVAL6229PD	EVAL BOARD FOR L6229PD SOIC	Learn More
EVAL6229QR	BOARD DEMO L6229Q BLDC MOT CTRL	Learn More

Features: L6235/L6229

7 to 52 V_DC operating voltage
Low R_DS(on) output:
- 0.3Ω typ L6229 series
- 0.7Ω typ L6235 series
Output current:
- 2.8 A_DC (5.6 A peak) L6229 series
- 1.4 A_DC (2.8 A peak) L6235 series
Operating frequency up to 100 kHz

Integrated stepping sequence generator
Twin integrated PWM (current control)
Full set of protection features:
- Programmable non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, SO, DIP, QFN

PowerSPIN: DMOS driver for three-phase brushless DC motor

Part Number	On-State Resistance	Current Output/Channel	Current Peak Output	Package
L6230PD	300 mOhm	2.8A	5.6A	20-SOIC	Learn More
L6230Q	300 mOhm	2.8A	5.6A	PowerSO-20	Learn More

Development Kits
STEVAL-IFN004V1	BOARD DEMO BLDC L6230/STM8S105	Learn More
EVAL6230QR	EVAL BOARD FOR THE L6230Q	Learn More

Features: L6230

7 to 52 V_DC operating voltage
Low R_DS(on)
Output current: 1.4 A_DC (2.8 A peak)
3 independent current senses
- Optimized for sensor-less control
- Compatible with sinusidal/ 6 steps control

Operating frequency up to 100 kHz
Full set of protection features:
- Non-dissipative current protection
- Cross conduction protection
- Thermal shutdown
- UVLO
Packages: powerSO, QFN
