Edge Lit Flower with our Kitronik Tricolour LED Boards

2025-07-24 | By Kitronik Maker

License: See Original Project Laser Cutters LEDs / Discrete / Modules

Guide by Kitronik Maker

Create that perfect gift for mum, using one of our Kitronik Tricolour LED Boards. This layered light effect display will look great on the mantel piece.

Grab the file, follow Kev's guide, and make your own. The designs can be personalised and changed in any way you like. Please share pics of your makes with us on social media so that we can share them with all of our customers.

covers_1

What we used:

Kitronik Tricolour LED Board.
Black Value Acrylic (for the base).
Clear Value Acrylic (for the etched flower).
2x 6mm M3 countersunk screws.
4x 12mm M3 pan head screws.
USB Type-A to Micro-B USB Noodle Cable.
This DXF.

sign_2

STEP 1 - Sowing the seeds:

Download the supplied DXF file for your laser cutter and then go to town. Etch and cut the stand and the flower elements from their respective acrylic colours.

cuts_3

STEP 2 - Attach the base:

Using the short 6mm M3 countersunk screws attach the board to the base layer and build the rest of the base elements around the board, making sure you have access to the USB connection and the on/off button. Attach the whole base unit together using the 4 12mm M3 pan head screws.

base_4
