Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ISO7330CDW | |
|---|---|
DigiKey Part Number | 296-42108-5-ND |
Manufacturer | |
Manufacturer Product Number | ISO7330CDW |
Description | DGTL ISOLTR 3KV 3CH GP 16-SOIC |
Manufacturer Standard Lead Time | 6 Weeks |
Customer Reference | |
Detailed Description | General Purpose Digital Isolator 3000Vrms 3 Channel 25Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width) |
Datasheet | Datasheet |
EDA/CAD Models | ISO7330CDW Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Packaging | Tube | |
Part Status | Active | |
Technology | Capacitive Coupling | |
Type | General Purpose | |
Isolated Power | No | |
Number of Channels | 3 | |
Inputs - Side 1/Side 2 | 3/0 | |
Channel Type | Unidirectional | |
Voltage - Isolation | 3000Vrms | |
Common Mode Transient Immunity (Min) | 25kV/µs | |
Data Rate | ||
Propagation Delay tpLH / tpHL (Max) | 58ns, 58ns | |
Pulse Width Distortion (Max) | 4ns | |
Rise / Fall Time (Typ) | 3ns, 2ns | |
Voltage - Supply | 3V ~ 5.5V | |
Operating Temperature | -40°C ~ 125°C | |
Mounting Type | Surface Mount | |
Package / Case | ||
Supplier Device Package | 16-SOIC | |
Base Product Number |
In-Stock: 1,142
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Tube
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $39.41000 | $39.41 |
| 10 | $29.97800 | $299.78 |
| 40 | $26.63025 | $1,065.21 |
| 120 | $24.76233 | $2,971.48 |
| 280 | $23.66675 | $6,626.69 |
| 520 | $23.01623 | $11,968.44 |
| 1,000 | $22.44148 | $22,441.48 |
| 2,520 | $21.78975 | $54,910.17 |
