Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
PDTC114ET,215 | |
|---|---|
DigiKey Part Number | 1727-5131-2-ND - Tape & Reel (TR) 1727-5131-1-ND - Cut Tape (CT) 1727-5131-6-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | PDTC114ET,215 |
Description | TRANS PREBIAS NPN 50V TO236AB |
Manufacturer Standard Lead Time | 8 Weeks |
Customer Reference | |
Detailed Description | Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased 50 V 100 mA 230 MHz 250 mW Surface Mount TO-236AB |
Datasheet | Datasheet |
EDA/CAD Models | PDTC114ET,215 Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | Nexperia USA Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Transistor Type | NPN - Pre-Biased | |
Current - Collector (Ic) (Max) | 100 mA | |
Voltage - Collector Emitter Breakdown (Max) | 50 V | |
Resistors Included | R1 and R2 | |
Resistor - Base (R1) | 10 kOhms | |
Resistor - Emitter Base (R2) | 10 kOhms | |
DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 5mA, 5V | |
Vce Saturation (Max) @ Ib, Ic | 150mV @ 500µA, 10mA | |
Current - Collector Cutoff (Max) | 1µA | |
Frequency - Transition | 230 MHz | |
Power - Max | 250 mW | |
Mounting Type | Surface Mount | |
Package / Case | TO-236-3, SC-59, SOT-23-3 | |
Supplier Device Package | TO-236AB | |
Base Product Number |
In-Stock: 36,036
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $0.99000 | $0.99 |
| 10 | $0.61700 | $6.17 |
| 100 | $0.38030 | $38.03 |
| 500 | $0.27446 | $137.23 |
| 1,000 | $0.23988 | $239.88 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 3,000 | $0.19570 | $587.10 |
| 6,000 | $0.17334 | $1,040.04 |
| 9,000 | $0.16191 | $1,457.19 |
| 15,000 | $0.14905 | $2,235.75 |
| 21,000 | $0.14143 | $2,970.03 |
| 30,000 | $0.13401 | $4,020.30 |
| 75,000 | $0.11770 | $8,827.50 |
| 150,000 | $0.10761 | $16,141.50 |
| 300,000 | $0.09913 | $29,739.00 |
