Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
MP6500GF-Z | |
|---|---|
DigiKey Part Number | 1589-1976-2-ND - Tape & Reel (TR) 1589-1976-1-ND - Cut Tape (CT) 1589-1976-6-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | MP6500GF-Z |
Description | IC MTR DRV BIPLR 4.5-35V 28TSSOP |
Manufacturer Standard Lead Time | 8 Weeks |
Customer Reference | |
Detailed Description | Bipolar Motor Driver Power MOSFET Logic 28-TSSOP-EP |
Datasheet | Datasheet |
EDA/CAD Models | MP6500GF-Z Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | Monolithic Power Systems Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Motor Type - Stepper | Bipolar | |
Motor Type - AC, DC | Brushed DC | |
Function | Driver - Fully Integrated, Control and Power Stage | |
Output Configuration | Half Bridge (4) | |
Interface | Logic | |
Technology | Power MOSFET | |
Step Resolution | 1, 1/2, 1/4, 1/8 | |
Applications | Printer | |
Current - Output | 2.5A | |
Voltage - Supply | 4.5V ~ 35V | |
Voltage - Load | 3.3V, 5V | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
Supplier Device Package | 28-TSSOP-EP | |
Base Product Number |
In-Stock: 3,864
Factory Stock: 5,000
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $23.79000 | $23.79 |
| 10 | $17.77300 | $177.73 |
| 25 | $16.26960 | $406.74 |
| 100 | $14.61760 | $1,461.76 |
| 250 | $13.82976 | $3,457.44 |
| 500 | $13.35494 | $6,677.47 |
| 1,000 | $12.96400 | $12,964.00 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 2,500 | $12.55150 | $31,378.75 |
| 5,000 | $12.30286 | $61,514.30 |
