0527931070 is out of stock and can be placed on backorder.
Available Substitutes:
Direct
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
0527931070 | |
|---|---|
DigiKey Part Number | WM11029TR-ND - Tape & Reel (TR) WM11029CT-ND - Cut Tape (CT) WM11029DKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | 0527931070 |
Description | CONN FPC TOP 10POS 1MM R/A |
Manufacturer Standard Lead Time | 20 Weeks |
Customer Reference | |
Detailed Description | 10 Position FPC Connector Contacts, Top 0.039" (1.00mm) Surface Mount, Right Angle |
Datasheet | Datasheet |
EDA/CAD Models | 0527931070 Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | Molex | |
Series | ||
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Flat Flex Type | FPC | |
Mounting Type | Surface Mount, Right Angle | |
Connector/Contact Type | Contacts, Top | |
Number of Positions | 10 | |
Pitch | 0.039" (1.00mm) | |
Termination | Solder | |
FFC, FCB Thickness | 0.30mm | |
Height Above Board | 0.122" (3.10mm) | |
Locking Feature | - | |
Cable End Type | Straight | |
Contact Material | Phosphor Bronze | |
Contact Finish | Tin Bismuth | |
Housing Material | Polyphenylene Sulfide (PPS) | |
Actuator Material | - | |
Features | Solder Retention | |
Voltage Rating | 50V | |
Operating Temperature | -20°C ~ 85°C | |
Material Flammability Rating | UL94 V-0 | |
Current Rating (Amps) | 0.5A | |
Contact Finish Thickness | - | |
Housing Color | - | |
Actuator Color | - | |
Mating Cycles | 10 | |
Base Product Number |
0 In Stock
Check Lead Time
Request Stock Notification
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $8.31000 | $8.31 |
| 10 | $7.05500 | $70.55 |
| 25 | $6.60880 | $165.22 |
| 50 | $6.29260 | $314.63 |
| 100 | $5.99210 | $599.21 |
| 250 | $5.61620 | $1,404.05 |
| 500 | $5.34800 | $2,674.00 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1,000 | $5.09256 | $5,092.56 |
| 2,000 | $4.84951 | $9,699.02 |
| 3,000 | $4.71277 | $14,138.31 |
| 5,000 | $4.54602 | $22,730.10 |
| 7,000 | $4.43944 | $31,076.08 |
| 10,000 | $4.32919 | $43,291.90 |
