Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
1578-3-57-15-00-00-03-0 | |
|---|---|
DigiKey Part Number | ED1636TR-ND - Tape & Reel (TR) ED1636CT-ND - Cut Tape (CT) ED1636DKR-ND - Digi-Reel® |
Manufacturer | |
Manufacturer Product Number | 1578-3-57-15-00-00-03-0 |
Description | CONN SPRING TARGET 1POS SMD |
Manufacturer Standard Lead Time | 6 Weeks |
Customer Reference | |
Detailed Description | Contact Spring Surface Mount |
Datasheet | Datasheet |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Manufacturer | Mill-Max Manufacturing Corp. | |
Series | ||
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Contact Type | Contact Pad | |
Mounting Type | Surface Mount | |
Maximum Working Height | - | |
Recommended Working Height | - | |
Minimum Working Height | - | |
Pad Layout Dimension | Circular - 0.078" (1.98mm) Dia, 0.055" (1.40mm) H | |
Operating Force - Initial | - | |
Operating Force - Mid Compression | - | |
Plunger Size | - | |
Features | - | |
Mating Cycles | - | |
Contact Material | Brass Alloy | |
Contact Finish | Gold | |
Contact Finish Thickness | 10.0µin (0.25µm) | |
Current Rating (Amps) | - | |
Material Flammability Rating | - | |
Operating Temperature | -55°C ~ 125°C | |
Base Product Number |
In-Stock: 46,201
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Cut Tape (CT) & Digi-Reel®
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $4.94000 | $4.94 |
| 10 | $4.22300 | $42.23 |
| 100 | $3.58590 | $358.59 |
| 500 | $3.20010 | $1,600.05 |
| 1,000 | $3.04724 | $3,047.24 |
Tape & Reel (TR)
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 4,000 | $2.76324 | $11,052.96 |
| 8,000 | $2.63139 | $21,051.12 |
| 12,000 | $2.55723 | $30,686.76 |
| 20,000 | $2.46676 | $49,335.20 |
| 28,000 | $2.40896 | $67,450.88 |
