Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ADUM110N0BRZ | |
|---|---|
DigiKey Part Number | 505-ADUM110N0BRZ-ND |
Manufacturer | |
Manufacturer Product Number | ADUM110N0BRZ |
Description | DGTL ISOLTR 3KV 1CH GP 8-SOIC |
Manufacturer Standard Lead Time | 10 Weeks |
Customer Reference | |
Detailed Description | General Purpose Digital Isolator 3000Vrms 1 Channel 150Mbps 75kV/µs CMTI 8-SOIC (0.154", 3.90mm Width) |
Datasheet | Datasheet |
EDA/CAD Models | ADUM110N0BRZ Models |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Packaging | Tube | |
Part Status | Active | |
Technology | Magnetic Coupling | |
Type | General Purpose | |
Isolated Power | No | |
Number of Channels | 1 | |
Inputs - Side 1/Side 2 | 1/0 | |
Channel Type | Unidirectional | |
Voltage - Isolation | 3000Vrms | |
Common Mode Transient Immunity (Min) | 75kV/µs | |
Data Rate | ||
Propagation Delay tpLH / tpHL (Max) | 13ns, 13ns | |
Pulse Width Distortion (Max) | 3ns | |
Rise / Fall Time (Typ) | 2.5ns, 2.5ns | |
Voltage - Supply | 1.7V ~ 5.5V | |
Operating Temperature | -40°C ~ 125°C | |
Mounting Type | Surface Mount | |
Package / Case | ||
Supplier Device Package | 8-SOIC | |
Base Product Number |
In-Stock: 467
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Tube
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $25.27000 | $25.27 |
| 10 | $16.05200 | $160.52 |
| 98 | $10.94776 | $1,072.88 |
| 196 | $9.90026 | $1,940.45 |
| 294 | $9.36850 | $2,754.34 |
| 588 | $8.57781 | $5,043.75 |
| 1,078 | $7.99229 | $8,615.69 |
| 2,548 | $7.40880 | $18,877.62 |
