Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
302A10019X | |
|---|---|
DigiKey Part Number | 626-1966-ND |
Manufacturer | |
Manufacturer Product Number | 302A10019X |
Description | CONN D-SUB RCPT 9POS SOLDER CUP |
Manufacturer Standard Lead Time | 12 Weeks |
Customer Reference | |
Detailed Description | 9 Position D-Sub Receptacle, Female Sockets Connector |
Datasheet | Datasheet |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Packaging | Bulk | |
Part Status | Active | |
Connector Style | ||
Connector Type | Receptacle, Female Sockets | |
Number of Positions | ||
Number of Rows | 2 | |
Mounting Type | ||
Shell Size, Connector Layout | 1 (DE, E) | |
Contact Type | Signal | |
Flange Feature | Housing/Shell (Unthreaded) | |
Termination | Solder Cup | |
Shell Material, Finish | Steel, Tin Plated | |
Contact Finish | Gold | |
Contact Finish Thickness | 8.00µin (0.203µm) | |
Ingress Protection | IP20 | |
Material Flammability Rating | UL94 V-0 | |
Current Rating (Amps) | 7.5A | |
Backset Spacing | - | |
Features | - | |
Voltage Rating | 125V | |
Color | Black | |
Contact Form | Stamped | |
Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled | |
Wire Gauge | 20 AWG | |
Contact Material | Copper Alloy | |
Operating Temperature | - | |
Base Product Number |
In-Stock: 454
Check for Additional Incoming Stock
Quantity
All prices are in HKD
Bulk
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1 | $8.80000 | $8.80 |
| 10 | $7.50600 | $75.06 |
| 25 | $7.03440 | $175.86 |
| 50 | $6.69880 | $334.94 |
| 100 | $6.37820 | $637.82 |
| 250 | $5.97800 | $1,494.50 |
| 500 | $5.69256 | $2,846.28 |
| 1,000 | $5.42076 | $5,420.76 |
| 2,500 | $5.08138 | $12,703.45 |
