PCB Design Tools for Optocouplers
Vishay's PCB design tools for optocouplers enable consumers to find footprints, schematic symbols, 3D, and SPICE models all in one place
Footprints, schematic symbols, and 3D models are available for Vishay’s optocouplers via SnapEDA’s online parts library, www.snapeda.com. These tools streamline the design process of Vishay’s optocouplers, solid-state relays, MOSFET drivers, and optical sensors and are free. Supported formats include Altium, Eagle, OrCad, Allegro, PADS, DXDesigner, and KiCad. The footprints were created to IPC-7351B standards, and are auto-verified using SnapEDA's proprietary automated verification technology.
Examples of these tools can be accessed via select product pages such as VOL617A-3T, LH1510AABTR, VO3150A-X007T, VEML6075 on www.digikey.com.
Optocouplers
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
 |  | VOL617A-3X001T | OPTOISOLATOR 5KV 1CH TRANS 4-SOP | 12220 - Immediate | $4.69 | View Details |
|  | ILD207T | OPTOISOLTR 4KV 2CH TRANS 8-SOIC | 6952 - Immediate | $11.03 | View Details |
|  | TCLT1600 | OPTOISOLATOR 5KV 1CH TRANS 4-SOP | 47207 - Immediate | $6.34 | View Details |
| | VOL617A-3T | OPTOISOLATOR 5KV 1CH TRANS 4-SOP | 4352 - Immediate | $4.86 | View Details |
|  | TCLT1007 | OPTOISOLATOR 5KV 1CH TRANS 4-SOP | 26814 - Immediate | $6.01 | View Details |
| | ILD217T | OPTOISOLTR 4KV 2CH TRANS 8-SOIC | 11661 - Immediate | $11.61 | View Details |
| | TCLT1003 | OPTOISOLATOR 5KV 1CH TRANS 4-SOP | 117476 - Immediate | $6.01 | View Details |
|  | VOM1271T | OPTOISO 3.75KV 1CH PHVOLT 4-SOP | 95460 - Immediate | $15.15 | View Details |
|  | TCMD1000 | OPTOISOLTR 3.75KV 1CH DARL 4-SOP | 15166 - Immediate | $6.34 | View Details |
|  | SFH6156-2T | OPTOISOLTR 5.3KV 1CH TRANS 4-SMD | 18890 - Immediate | $4.36 | View Details |
Optical Sensors
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
|  | VCNL3020-GS08 | SENSOR OPT IR 10 SMD | 8005 - Immediate | $17.37 | View Details |
|  | VCNL4035X01-GS08 | SENSOR OPT 550NM AMBIENT 8 SMD | 1077 - Immediate | $16.05 | View Details |
|  | VCNL4040M3OE-H5 | SENSOR OPT 550NM AMBIENT 8 SMD | 1493 - Immediate | $16.55 | View Details |
| | VCNL4040M3OE | SENSOR OPT 550NM AMBIENT 8 SMD | 17648 - Immediate | $13.75 | View Details |
|  | VCNL4100 | SENSOR OPT 550NM AMBIENT 10 SMD | 0 - Immediate | $41.90 | View Details |
|  | VCNL4200 | SENSOR OPT 550NM AMBIENT 10 SMD | 20320 - Immediate | $20.58 | View Details |
|  | VEML6030-GS15 | SENSOR OPT 550NM AMBIENT 6 SMD | 18207 - Immediate | $12.59 | View Details |
|  | VEML6030 | SENSOR OPT 550NM AMBIENT 6 SMD | 4430 - Immediate | $12.59 | View Details |
 | VEML6070 | SENSOR OPT 335NM UV 6 SMD | 0 - Immediate | See Page for Pricing | View Details | |
|  | VEML6075 | SENSOR OPT 330NM365NM UV 4 | 0 - Immediate | $16.05 | View Details |
Solid-State Relays
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
|  | LH1500AABTR | SSR RELAY SPST-NO 150MA 0-350V | 6870 - Immediate | $18.85 | View Details |
|  | LH1501BABTR | SSR RELAY SPST-NC 150MA 0-350V | 2907 - Immediate | $35.32 | View Details |
|  | LH1502BACTR | RELAY SPST-NO/NC 150MA 0-350V | 1139 - Immediate | $41.16 | View Details |
|  | LH1510AABTR | SSR RELAY SPST-NO 200MA 0-200V | 7105 - Immediate | $21.90 | View Details |
|  | LH1511BABTR | SSR RELAY SPST-NC 200MA 0-200V | 407 - Immediate | $35.32 | View Details |
|  | LH1512BACTR | RELAY SPST-NO/NC 200MA 0-200V | 11441 - Immediate | $43.88 | View Details |
|  | LH1518AABTR | SSR RELAY SPST-NO 300MA 0-250V | 10818 - Immediate | $23.05 | View Details |
|  | LH1520AACTR | SSR RELAY SPST-NO 110MA 0-350V | 964 - Immediate | $38.36 | View Details |
|  | LH1522AACTR | SSR RELAY SPST-NO 120MA 0-200V | 4403 - Immediate | $41.41 | View Details |
 | LH1523BACTR | SSR RELAY SPST-NC 200MA 0-200V | 0 - Immediate | $49.89 | View Details |
MOSFET Drivers
| Image | Manufacturer Part Number | Description | Available Quantity | Price | View Details | |
|---|---|---|---|---|---|---|
|  | VO3150A-X007T | OPTOISO 5.3KV 1CH GATE DVR 8DIP | 2306 - Immediate | $15.23 | View Details |
 | VOL3120-X001T | OPTOISO 5.3KV 1CH GATE DVR 5LSOP | 0 - Immediate | See Page for Pricing | View Details | |
| | VO3120 | OPTOISO 5.3KV 1CH GATE DVR 8DIP | 1792 - Immediate | $11.61 | View Details |
| VOL3120T | OPTOISO 5.3KV 1CH GATE DVR 5LSOP | 0 - Immediate | See Page for Pricing | View Details | |
|  | VO3120-X007T | OPTOISO 5.3KV 1CH GATE DVR 8SMD | 6640 - Immediate | $14.82 | View Details |
Published: 2017-12-20
