ZVS Regulators

Power That Delivers

...at HIGHER temperatures

A regulator is only as good as the power it can deliver in the actual environment it will be used in, Vicor ZVS Regulators deliver more power at higher temperatures versus the competition.

...at HIGHER efficiencies

The heart of any ZVS regulator is the zero voltage switching topology that enables lower losses from higher input voltages creating higher conversion efficiency than the competition.

...in a SMALLER size

All active components integrated into the package.

...the FIRST time

• Predefined design
• Minimal input/output ceramic
  capacitance needed
• Reference schematic & layout provided

Features

• Able to convert from 48 V directly to point of load
• Parallel capable with either single wire current sharing or phase delayed interleaving
• Requires only minimal external components, and no external compensation required
• Capable of delivering up to 10 A with peak efficiency greater than 96%
• Compact 10 x 10 x 2.5 mm thermally adept SMT package
• Wide operating range
• Simple to use; fast development time

Benefits

• Can eliminate a conversion stage, increasing efficiency, while reducing size and cost
• Enables scalability for higher power
• Easy to use
• Power rating compatible with isolated DC-DC converters with higher efficiency
• Saves space and lower profile; no heat sink required
• High efficiency
• Flexible and rich feature set
