Protect from Abrasion, Corrosion, and Noise
TE Connectivity (TE) heat shrink tubing provides electrical insulation, mechanical protection, environmental sealing, and strain relief for applications such as back-end connector sealing, breakouts, and connector-to-cable transitions. It is a solid alternative to taping, molding or potting. When heated, it conforms to the size and shape of the substrate beneath, enabling quick and easy installation. Its high expansion ratio makes it possible to repair most damaged cable jackets without removing connectors. Available in a wide range of materials, colors, and sizes, heat shrink tubing is delivered in forms such as spools, 1.2 m lengths, and cut pieces. Clear types permit inspection of covered components and offer excellent transmittance of light.
*TE Connectivity, TE Connectivity (logo), and TE are trademarks.
- Products by Type
- Products by Applications
Single Wall - Insulate and protect quickly
Gain superior insulation, strain relief, and protection against mechanical damage through the use of single wall tubing.
Single wall heat shrink tubing insulates, provides strain relief, and protects against mechanical damage and abrasion. Our heat shrink tubing offers a high-performance alternative to standard approaches for insulation, such as taping and molding in place. The tubing comes in a wide range of sizes, colors, and materials. When heated, it shrinks to conform to the size and shape of the underlying material - making installation fast and easy.
VERSAFIT V2
Highly flame-retardant, very flexible, low-shrink-temperature metric-sized polyolefin tubing
VERSAFIT V4
Very-thin-wall, very flexible, highly flame-retardant, low-shrink temperature, imperial and metric sized polyolefin tubing
RNF-100
Flexible, flame-retardant, general purpose polyolefin tubing
SWFR X2
Very flexible, low-shrink temperature, highly flame-retardant, polyolefin tubing with no added halogens
SWFR X4
Very-thin-wall, very flexible, low-shrink-temperature, highly flame-retardant, polyolefin tubing with no added halogens
Dual Wall - Resist moisture while insulating, protecting
Protects against moisture and corrosive environments, while providing electrical insulation and mechanical protection using engineered adhesives.
When corrosion protection and sealing are required, use TE's heat shrink dual wall tubing. Dual wall tubing products consist of a crosslinked outer jacket and an inner layer of adhesive or encapsulant. During installation, the adhesive or encapsulant lining melts and flows, creating a moisture-resistant protective barrier. Benefits of this type of tubing include controlled amounts of adhesive and consistent results; compliance with AMS-DTL-23053 standards; UL recognition/CSA certification; and RoHS Compliant.
ES1000
Clear, high-shrink-ratio, adhesive-lined semirigid polyolefin tubing
ES2000
Flame-retardant, high-shrink-ratio, adhesive-lined semirigid polyolefin tubing
QSZH-125
High-shrink-ratio, adhesive-lined semirigid polyolefin tubing
SCT
Flame-retardant, adhesive-lined semirigid polyolefin tubing (extended temperature range)
ATUM
High-shrink-ratio, adhesive-lined polyolefin tubing
HTAT
Semiflexible, high-shrink-ratio, adhesive-lined polyolefin tubing
BATTU
Flame retardant, adhesive-lined tubing
Heavy Duty - Protect with heavy duty tubing
When an application requires more robust protection, heavy duty heat-shrinkable tubing is the cost-effective solution for optimizing insulation and protection.
When an application requires more robust protection, heavy duty heat shrink tubing provides cost-effective solutions. Heavy duty tubing offers toughness, durability, excellent insulation, abrasion protection, mechanical abuse reliability, and resistance to chemicals, moisture and oils when industry standards require rugged tubings. The thick wall insulates and protects. Benefits of this type of tubing include controlled amounts of adhesive and consistent results, compliance with AMS-DTL-23053 standards, and multiple products offered in flame-retardant (FR) versions.
BSTS/BSTS-FR
Rugged, thick wall, general purpose polyolefin tubing
HF
High-flex, heavy wall polyolefin tubing
HRHF/HRNF/HRSR
High-ratio, durable heavy wall polyolefin tubing
HRHT
High-ratio, high-temperature polyolefin tubing
RHW
Rugged, heavy wall, adhesive-lined polyolefin tubing
RMW
Medium wall, general purpose polyolefin tubing
SST/SST-FR
Thick wall, adhesive-lined polyolefin tubing
Harnessing Tubing - Engineered for Fluid Resistance and Flexibility
Our high-performance heat shrinkable tubing products are designed to meet harsh environments required by most ruggedized harness designs. For more than 50 years, our general-purpose Raychem harnessing tubing have been designed to withstand exposure to temperatures in excess of 200°C. The use of Raychem harnessing tubing allows simple design and cost effective custom harnesses. This product is specifically designed for aerospace and military platforms.
Features
- Heat shrinkability
- High temperature materials
- Excellent insulation property
- Few sizes cover a large range of wire diameters
- Enabling the design of harnesses for harsh environments
- Provides insulation from damaged wires
DR-25/DR-25-TW
Flexible, chemical and abrasion resistant tubing
RW-200/RW-200E
Chemical-resistant, high-temperature fluoroelastomer tubing
RT-555
Fluid-resistant, chemical-resistant, fluoropolymer tubing with extended temperature range
NTFR
Very flexible, rugged neoprene elastomer heat shrink tubing
SRFR
Highly flexible silicone rubber tubing
Auto & Truck Harnessing - Heat Shrink Tubing for Automotive, Truck, Bus, and Off-Road Vehicles
Designed for demanding environments, TE's heat shrink tubing products provide long-term protection against moisture ingress, corrosion, mechanical damage, and extreme temperature.
TE provides a complete solution for heat shrink tubing products, including services for installation equipment, application engineering support, and training. TE’s Raychem heat shrink tubing products are made from uniquely formulated materials that have been enhanced by radiation cross-linking, a technology that TE has pioneered. Our product design provides a repeatable, reliable, shrink to fit installation compatible with many manufacturing processes. TE's single wall tubing products can be used wherever reliable insulation, strain relief, and protection from mechanical abrasion and chemical abuse is needed. These are an ideal way to identify or code components, or simply use them to enhance aesthetics. TE's adhesive-lined product range shows its strength where sealing and encapsulation are critical requirements, as well as demonstrating many of the features of the single wall products. The inner adhesive can deliver a true seal against moisture and fluid ingress.
ES1000
Clear, high-shrink-ratio, adhesive-lined semirigid polyolefin tubing
ES2000
Flame-retardant, high-shrink-ratio, adhesive-lined semirigid polyolefin tubing
SCT
Flame-retardant, adhesive-lined semirigid polyolefin tubing (extended temperature range)
BATTU
Flame retardant, adhesive-lined tubing
ATUM
High-shrink-ratio, adhesive-lined semirigid polyolefin tubing
HTAT
Semiflexible, high-shrink-ratio, adhesive-lined polyolefin tubing
QSZH-125
High-shrink-ratio, adhesivelined semirigid polyolefin tubing
ES-CAP
High-shrink-ratio, adhesive-lined semirigid polyolefin caps
LSTT
Low-shrink temperature, non-flame-retardant, heat-shrinkable, polyolefin tubing
SWFR X2
Very flexible, low-shrink temperature, highly flame-retardant, polyolefin tubing with no added halogens
SWFR X4
Very-thin-wall, very flexible, low-shrink temperature, highly flame-retardant, polyolefin tubing with no added halogens
RayBlock
Heat-shrinkable water blocking system
Special Purpose - High Performance Tubing for Demanding Requirements
TE offers a wide selection of heat shrink tubing to meet your most demanding design requirements.
TE special-purpose tubing is available in a variety of materials, colors, shrink ratios, and sizes. Compliant with international standards, TE heat shrink tubing offers alternative high-performance options for wide-reaching applications. When heated, TE tubing shrinks to conform to the size and shape of the underlying material – making installation quick and easy.
RW-175
High-temperature, chemical-resistant polyvinylidene fluoride tubing
HFT5000
Heat-shrinkable fabric tubing
CRN
Semirigid polyolefin tubing
TFE/TFER
High-temperature, chemically inert modified PTFE tubing
