LUMAWISE Solderless LED Holders

LUMAWISE small, low-profile LED holders from TE Connectivity AMP provide a quick and easy solderless connection to the specific LED

Image of TE Connectivity's LUMAWISE Solderless LED HoldersTE Connectivity AMP announces the latest range of TE's LED holder solutions which enable the adoption of Bridgelux, Cree, Citizen, Everlight, Nichia, OSRAM, Seoul Semiconductor, and Sharp COB LEDs. The TE Connectivity Solderless LED holders are small, low-profile solutions that provide a quick and easy solderless connection to the specific LED.

Providing reliable power connection, mechanical attachment, proper thermal force, and secondary optics attachment features for chip on board and array LEDs enables designs to be more reliable, easier to use, and faster to market.

Features
  • Contacts allow for a reliable and consistent connection to the LED
  • Eliminates the need for hand soldering LEDs, keeping the LED from unnecessary heat and the surface clear of solder flux spatters
  • Metal spring option enhances heat sink pressure to the thermal interface material (TIM) without damaging (ceramic) substrates
  • Offers design flexibility with one or two piece configurations
  • The housing design minimizes shadowing to maximize LED output
  • Flat design offers an optic landing area for ease of assembly

LUMAWISE Solderless LED Holders

ImageManufacturer Part NumberDescriptionAvailable QuantityPrice
LUMAWISE LED HOLDER Z50 LOW PRO2213254-1LUMAWISE LED HOLDER Z50 LOW PRO9893 - Immediate$31.61View Details
LUMAWISE Z50 LED HOLDER 2828 GEN2213480-1LUMAWISE Z50 LED HOLDER 2828 GEN1115 - Immediate$32.84View Details
SR RECEPTACLE ASSEMBLY2213858-1SR RECEPTACLE ASSEMBLY5503 - Immediate$74.88View Details
Z50 OPTIC CLIP TYPE 12213194-1Z50 OPTIC CLIP TYPE 11391 - Immediate$13.63View Details
LUMAWISE Z35 LED HOLDER FOR PAN3-2213678-3LUMAWISE Z35 LED HOLDER FOR PAN469 - Immediate$20.36View Details
Z35 MINI LED HOLDER 13.5*13.5MM2213678-5Z35 MINI LED HOLDER 13.5*13.5MM996 - Immediate$20.45View Details
LUMAWISE LED HOLDER Z50 STD PROF2213407-2LUMAWISE LED HOLDER Z50 STD PROF803 - Immediate$25.70View Details
40MM BASE, MODULE ASSEMBLY, SR,2213837-140MM BASE, MODULE ASSEMBLY, SR,6447 - Immediate$49.68View Details
2PC REQ/ASSEM LED SOCKET CITIZEN2-2154857-22PC REQ/ASSEM LED SOCKET CITIZEN3414 - Immediate$11.33View Details
LUMAWISE LED HOLDER Z50 LOW PROF2213407-1LUMAWISE LED HOLDER Z50 LOW PROF9517 - Immediate$22.09View Details
LUMAWISE ENDURANCE S 40MM DOME C1-2329013-1LUMAWISE ENDURANCE S 40MM DOME C371 - Immediate$22.09View Details
LUMAWISE LED HOLDER Z50 LOW PROF2213382-1LUMAWISE LED HOLDER Z50 LOW PROF135 - Immediate$22.09View Details
RAIN-SKIRT LUMAWISE ENDURANCE S1-2337216-1RAIN-SKIRT LUMAWISE ENDURANCE S1791 - Immediate$24.80View Details
LUMAWISE Z35 LED HOLDER FOR COUN3-2213678-4LUMAWISE Z35 LED HOLDER FOR COUN1677 - Immediate$25.21View Details
LUMAWISE LED HOLDER2325807-3LUMAWISE LED HOLDER1555 - Immediate$26.36View Details
LUMAWISE LED HOLDER2325807-2LUMAWISE LED HOLDER1106 - Immediate$26.36View Details
LUMAWISE LED HOLDER1-2325807-2LUMAWISE LED HOLDER149 - Immediate$26.36View Details
1 PC LED SOCKET CREE CXA15XX5-2154874-21 PC LED SOCKET CREE CXA15XX369 - Immediate$27.75View Details
LUMAWISE ENDURANCE S 80MM DOME C1-2328823-1LUMAWISE ENDURANCE S 80MM DOME C5630 - Immediate$31.45View Details
Z50 LED HOLDER LOW PROFILE SH2213130-1Z50 LED HOLDER LOW PROFILE SH174 - Immediate$31.61View Details
