            GRF1 50 Ohm Ganged Micro-Miniature RF Connectors and Cables
                    Samtec's ganged, multi-position RF blocks and cable assemblies are ideal when space is limited


Samtec's GRF1 50 Ohm ganged micro-miniature connectors and cable assemblies are rated up to 5.31 GHz/10.7 Gbps at 152.00 mm. These ganged solutions are ideal when space is limited. Optional threaded inserts are also available.

Resources

Features

Performance: up to 5.31 GHz/10.7 Gbps at 152.00 mm
High-performance, rugged contact

5.00 mm (0.1969") pitch
Optional threaded inserts

Applications

5G networking
Industrial
Military/aerospace
Test connectivity
Medical

Broadcast video
Automotive
AI/machine learning
Instrumentation

Connectors

Manufacturer Part Number	Description	Connector Type	Mounting Type	Number of Ports	Available Quantity	Price	View Details
GRF1-J-P-08-E-ST-TH1	CONN MMCXV JACK STR 50 OHM PCB	Jack, Female Socket	Through Hole	8	9 - Immediate	$121.03	View Details
GRF1-J-P-04-E-ST-TH1-E	CONN MMCXV JACK STR 50 OHM PCB	Jack, Female Socket	Through Hole	4	48 - Immediate	$91.22	View Details
GRF1-J-P-02-E-ST-TH1-E	CONN MMCXV JACK STR 50 OHM PCB	Jack, Female Socket	Through Hole	2	0 - Immediate	$83.26	View Details
GRF1-P-P-04-E-ST-TH1	CONN MMCXV PLUG STR 50 OHM PCB	Plug, Male Pin	Through Hole	4	594 - Immediate 1595 - Factory Stock	$127.60	View Details
GRF1-J-P-06-E-ST-TH1-E	CONN MMCXV JACK STR 50 OHM PCB	Jack, Female Socket	Through Hole	6	36 - Immediate	$132.03	View Details
GRF1-P-P-08-E-ST-TH1	CONN MMCXV PLUG STR 50 OHM PCB	Plug, Male Pin	Through Hole	8	10 - Immediate	$306.43	View Details
GRF1-P-P-02-E-ST-TH1	CONN MMCXV PLUG STR 50 OHM PCB	Plug, Male Pin	Through Hole	2	2368 - Immediate 986 - Factory Stock	$65.85	View Details
GRF1-J-P-02-E-ST-TH1	CONN MMCXV JACK STR 50 OHM PCB	Jack, Female Socket	Through Hole	2	469 - Immediate 116 - Factory Stock	$48.94	View Details
GRF1-P-P-06-E-ST-TH1	CONN MMCXV PLUG STR 50 OHM PCB	Plug, Male Pin	Through Hole	6	14 - Immediate	$236.97	View Details
GRF1-J-P-02-E-RA-TH1	CONN RF JACK 1X2	Jack, Female Socket	Through Hole, Right Angle	2	187 - Immediate 125 - Factory Stock	$73.73	View Details

Cables

Manufacturer Part Number	Description	Length	Available Quantity	Price	View Details
GRF1-P-C-04-1000-C1-S-S	COAX CBL MMCXV TO CABLE 3.3'	39.4" (1.0m) 3.3'	4 - Immediate	$401.68	View Details
GRF1-P-C-08-1000-C1-S-S	COAX CBL MMCXV TO CABLE 3.3'	39.4" (1.0m) 3.3'	5 - Immediate	$731.52	View Details
GRF1-P-C-04-0300-C1-S-S	COAX CBL MMCXV TO CABLE 11.8"	11.811" (300.00mm)	0 - Immediate	See Page for Pricing	View Details
GRF1-P-C-04-0100-C1-S-S	COAX CBL MMCXV TO CABLE 3.9"	3.937" (100.00mm)	0 - Immediate	See Page for Pricing	View Details
GRF1-P-C-08-0100-C1-S-S	COAX CBL MMCXV TO CABLE 3.9"	3.937" (100.00mm)	0 - Immediate	$492.99	View Details
