Push-In Plus Technology

Even in Europe and America, where screwless terminals are common, push-in terminals are just becoming more prominent in industrial applications. The reason for their slow growth in popularity has been their stiff springs that hold the wires in place, which make it difficult to insert wires. That is why Omron developed new Push-in Terminal Blocks that achieve both less insertion force and firm wire holding ability. Because they are so innovative, we call them Push-In Plus Terminal Block.

Features & Benefits

  • Significantly reduced wiring work
  • No retightening
  • Less insertion force required
  • Advanced design for firm hold
  • Both hands free for wiring
  • Relays
  • Power Supplies
  • Monitor Products
  • Panel Mount Switches

Relays

G2RV-SR500 Low Profile Relay

Features and Benefits

  • 25% lower profile than conventional products, contributing to a smaller control panel
  • Opening and closing ability with one pole 6 A slim shape
  • Micro load products for one pole 50 mA using gold-plated contacts for small load switching also available
  • Since G2RV has a transparent case, confirming the state of the contact with the naked eye is possible
  • Screw terminal block models are available
  • Plug-in type terminal has strong mechanical pins that do not bend

G3RV-SR500 Low Profile SSR

Features and Benefits

  • 25% lower profile than conventional products, contributing to a smaller control panel
  • Optimal slim, high frequency, high-speed opening and closing SSR (solid state relay)
  • Slim shape with a switching capacity up to 3 A (DC), and 2 A (AC)
  • Because MOSFET is used for the outlet element for the DC load, opening and closing load of 100 μA to 3 A is possible
  • Check operating status at a glance with the operating display LED
  • Mounted I/O SSR (solid-state relay) uses plug-in terminals with strong mechanical pins that do not bend

G3PJ Solid State Relay

Features and Benefits

  • Single-phase SSR for low heat generation
  • Surge pass protection improved
  • Models available with Push-In Plus input terminals
  • RoHS compliant

Power Supplies

S8VK-S Push-In Terminals Power Supply

Omron’s S8VK-S feature a Push-In Plus technology that was independently developed by OMRON for easy wire insertion and firm wire holding ability. It’s as easy as inserting to an earphone jack: No tools are required. They help reduce the time and work involved in wiring. The advanced mechanism design technology and manufacturing technology produced a spring that ensures better workability and reliability

Features and Benefits

  • Operation possible at ambient temperatures from -40 to 70°C
  • DC input supported (90 to 350 VDC)
  • Power boost function at 120%
  • Horizontal side-by-side mounting
  • Vibration resistance to 5G, and 300-VAC abnormal input voltage supported for 1 second
  • PCB coating protects against dust, corrosive gas and humidity
  • Certification for 3000m altitude

Monitor Products

K8DT

Features and Benefits

  • Motor protection, temperature monitoring and water level control
  • Push-In Plus technology positioned in front to save wiring time
  • More energy efficient by consuming less power
  • Low isolation capacitance (10 pF max.)
  • Can be mounted side-by-side in panels

K7L

Features and Benefits

  • Liquid leakage sensor
  • Compatible with Push-In Plus sockets
  • Models for long-distance wiring up to 400m
  • Ribbon Electrode Bands and Point sensors available
  • UL Listed when used with Push-In Plus Terminal Sockets

Panel Mount Switches

A22NN and A30NN Series 22 & 30mm Pushbutton Switch

Features and Benefits

  • Meet global safety standards.
  • The buttons and bezels come in a wide variety of colors, shapes, and materials.
  • Easy-to-operate lock lever for secure locking.
  • Easy-mounting Contact Blocks provide finger protection.
  • No loose connections of wiring means maintenance-free use. (Push-In Plus terminal block type)

Screw Styled or Push-In Terminal Contact Blocks

Features and Benefits

  • Improved wiring visibility through to a modified wiring direction. (Push-In Plus terminal block type)
  • Screw terminal block structure is compatible with round crimp terminals. (Screw terminal block type)
  • The terminals can be secured even when a contact block is mounted. (Screw terminal block type)
  • Contact Blocks can be attached in any direction for easy assembly
  • Easy-mounting Contact Blocks provide finger protection

A22mm and A30mm Accessories

Features and Benefits

  • Matching Accessories for a professional appearance
  • Enclosures with pre-punched holes
  • Lockable covers to protect switches
  • Shrouds and legend plates
  • Replacement Keys
  • Wire trapping switch blocks
