NKK SmartDisplay™
OLED & LCD Programmable Switches & Displays
By combining the functionality of an electromechanical pushbutton or rocker switch with a graphic programmable OLED or LCD display, the SmartDisplay is a space-saving, dynamic, multi-function device. A wide array of SmartDisplay products are available from full-screen OLED to compact LCD.
Features
- Fully programmable, HMI solution
- Combines function keys with a versatile display
- Capable of running full motion video
- Tactile feel
- LCD or OLED display
Improving user experience by simplifying the HMI design, SmartDisplay integrates easily with embedded systems to decrease complexity and increase usability.
From audio broadcast and communications systems to medical, aerospace and defense applications, implementing SmartDisplay into panel designs helps to revolutionize the switch interface.
- OLED & LCD Programmables
- Engineering and Development Kits
- Accessories
- Additional Content
SmartDisplay OLED Programmables
ISC15ANP4 OLED Pushbutton
64 x 48 Programmable Color Display Video Capability; 180° Viewing Angle High Definition, Excellent Contrast
ISC01P OLED Display
52 x 36 Programmable Color Display Video Capability; 180° Viewing Angle High Definition, Excellent Contrast
IS18WWC1W OLED SmartDisplay Rocker
96 x 64 Programmable Display White Monochrome OLED Display Exceptional Contrast; 180° Viewing Angle; IP64 Rating
ISF15ACP4 Frameless OLED Pushbutton
96 x 64 Programmable Color Display Video Capability; 180° Viewing Angle High Definition, Excellent Contrast
SmartDisplay LCD Programmables
IS15EBFP4RGB-09YN Wide View LCD 64 x 32 Pushbutton
RGB LED Backlight; Black and White LCD; Standard Travel
IS15EBFP4RGB Miniature Pushbutton Switches
Wide View/Long Travel LCD 64 x 32
IS01EBFRGB Wide View 64 x 32 Display
64 colors of backlighting can be controlled dynamically. Display with LCD, RGB LED backlighting.
IS15ESBFP4RGB Wide View Compact LCD 64 x 32
Pushbutton switch with LCD, RGB LED backlighting. Incorporated bitmap display function.
IS15BBFP4RGB Wide View LCD 36 x 24 RGB Pushbutton
Programmable Display; Resolution: 36 x 24 Pixels Backlight RGB; Black & White LCD Up to 3 Lines with 6 Characters Each
IS15BAFP4CF Wide View LCD 36 x 24 Bicolor Pushbutton
Programmable Display; Resolution: 36 x 24 Pixels Backlight Red/Green; Black & White LCD Up to 3 Lines with 6 Characters Each
IS01BBFRGB Wide View 36 x 24 RGB Display
Programmable Display; Resolution: 36 x 24 Pixels Backlight RGB; Black & White LCD Up to 3 Lines with 6 Characters Each
IS15BSBFP4RGB Wide View Compact LCD 36 x 24 RGB Pushbutton
Programmable Display; Resolution: 36 x 24 Pixels Backlight RGB; Black & White LCD Up to 3 Lines with 6 Characters Each
IS15BSAFP4CF Wide View Compact LCD 36 x 24 Bicolor Pushbutton
Programmable Display; Resolution: 36 x 24 Pixels Backlight Red/Green; Black & White LCD Up to 3 Lines with 6 Characters Each
Single Switch Solution DEM Kit
A plug and play controller/indicator device that can both monitor and control.
Engineering Kit - IS-ENG-KIT-7-FS
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-7-FF
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-8-R
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-6-DH
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-6-SH
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-7-DS
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-5-BC
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-5-DC
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-6-CH
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
Engineering Kit - IS-ENG-KIT-5-SC
Simplified design allows control of up to two SmartDisplay products or one OLED Rocker.
LED Rocker Development Kit - IS-DEV KIT-8
One OLED Rocker switch on a PC board with flash memory, power and programming connections.
OLED Display Development Kit - IS-DEV KIT-7D
Two OLED displays on a PC board with flash memory, power and programming connections.
64 x 32 Pushbutton Development Kit - IS-DEV KIT-6
Two 64 x 32 pushbuttons on a PC board with flash memory, power and programming connections.
64 x 32 Compact Pushbutton Development Kit - IS-DEV KIT-6C
Two 64 x 32 compact pushbuttons on a PC board with flash memory, power and programming connections.
64 x 32 Display Development Kit - IS-DEV KIT-6D
Two 64 x 32 displays on a PC board with flash memory, power and programming connections.
36 x 24 RGB Pushbutton Development Kit - IS-DEV KIT-5
Two 36 x 24 RBG pushbuttons on a PC board with flash memory, power and programming connections.
6 x 24 Compact Pushbutton Development Kit - IS-DEV-KIT-5C
Two 36 x 24 RBG compact pushbuttons on a PC board with flash memory, power and programming connections.
Development Kit - IS18WWC1W-K
SmartDisplay™ Switches with Programmable Display Electromechanical Evaluation Board.
Accessories
Cable for OLED Rocker
AT715 Connector Cable (500 mm)/19.685"
Serial Cable
Serial cable for Dev Kits RJ11 to DB9
Power Supply
Power supply for Dev Kits. Input 120 V; Output 9 V, 0.5 A
Power Supply
Power supply for Dev Kits. Input 100 to 240 V; Output 9 V, 1.4 A
