Premo-Flex Cables and Easy-on Connectors: A Complete Flat Flexible Connectivity Solution from Molex

FFC-FPC Cables and Connectors Interactive Guide
Resources

	STEP 1 Choose your connector -OR- Identify Pitch Circuit count plating	STEP 2 Specifications Length Flex life cycles Contact layout type A = Same Side Contacts D = Opposite Side Contacts	STEP 3 Additional requirements Temperature Superior retention Speed
	0.25MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
MINIATURIZATION	15014	502078	Gold plating
MINIATURIZATION	15014	503300	Gold plating
	0.30MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
MINIATURIZATION	15015	502598	Gold plating
	15031	504754	Gold plating with notches
	15032	503566	Gold plating with ears
	0.40MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
HIGH-RETENTION SOLUTION	15025	220363	Superior retention
	0.50MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
ULTRA-FLEXIBLE	15166	52435	Tin plating; Tin plating, shielded; Gold plating
FLEXIBLE	15266	54104
EXTRA-FLEXIBLE	98266	52437
ELECTROMAGNETIC INTERFERENCE (EMI) PROTECTION	15366	501951
		52559
		78119
		78127
FLEXIBLE	15020	52435	Gold plating
ULTRA-FLEXIBLE	15120	54104
FLEXIBLE	15027	52437
		54132
		52745
		52746
		54550
		501951
		503480
		505110
		51281
		78119
		54548
		78127
SUPERIOR RETENTION	15018	505110	Gold plating with ears
	15466	505278	Tin plating with ears
	15016	200485	Gold plating; One-Touch
HIGH SPEED	15021	502244	Gold plating; LVDS
	15021	502231
	15022	501786
	15022	501864
	15023	503908
	15026	200485
	1.00MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
FLEXIBLE	15039	52207	Gold plating
		52271
		52610
		200528
		52808
ULTRA-FLEXIBLE	15167	52207	Tin plating
		52271
		52610
FLEXIBLE	15267	52207
		52271
		52610
EXTRA-FLEXIBLE	98267	52207
		52271
		52610
SUPERIOR RETENTION	15019	200528	Gold plating with ears
SUPERIOR RETENTION	15467	200529	Tin plating with ears
	1.00MM PITCH HYBRID RFC
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
DIRECT TO BOARD	15061	52207	Hybrid RFC
		52271
		52610
		52808
		52793
		52852
		52806
		52807
	1.00MM PITCH HOT BAR SOLDER
	15067	Delivering superior signal integrity through durable, permanent direct-to-PCB connections in high vibration environments and available in a variety of pitches, circuit sizes and terminations.
	1.25MM PITCH
	Premo-Flex Cable Jumpers	Easy-on Connectors	Features
DIRECT TO BOARD	15168	5597
	15268
	98268
