MAX14777 Quad Beyond-the-Rails™ -15 V to +35 V Analog Switch

Quad SPST Beyond-the-Rails switch from Analog Devices simplifies power supplies

Image of Analog Devices' MAX14777 Quad Beyond-the-Rails™ -15 V to +35 V Analog SwitchAnalog Devices' MAX14777 quad SPST switch supports analog signals above and below the rails with a single 3.0 V to 5.5 V supply. The device features a selectable -15 V/+35 V or -15 V/+15 V analog signal range for all switches. Each switch has a separate control input to allow independent switching, making the device an alternative to opto-relays in applications that do not need galvanic isolation. The IC features 10 Ω (max) on-resistance, and 9 mΩ (typ) RON flatness, along with a low 50 nA (max at +85°C) on-leakage. For maximum signal integrity, the device keeps this performance over the entire common-mode voltage range. Each switch can carry up to 60 mA (max) of continuous current in either direction. The MAX14777 is available in a 20-pin (4 mm x 4 mm) TQFN package and is specified over the -40°C to +105°C temperature range.

Features and Benefits
  • Simple, flexible board design, selectable -15 V / 15 V signal range for lower supply current, -15 V / 35 V Beyond-the-Rails™ signal range from a single 3.0 V to 5.5 V supply, 60 mA maximum current through each switch and 1.62 V to 5.5 V logic interface
  • High-performance 10Ω RON (max.)
  • 150 mΩ (max.) RON flatness
  • ±50 nA (max.) on-Leakage at TA = 85°C

Quad SPST Switch

ImageManufacturer Part NumberDescriptionNumber of CircuitsOn-State Resistance (Max)Available QuantityPrice
IC SWITCH SPST-NOX4 10OHM 20TQFNMAX14777GTP+IC SWITCH SPST-NOX4 10OHM 20TQFN410Ohm2037 - Immediate
375 - Factory Stock		$67.26View Details
Published: 2013-11-18

Related Product Training Modules

Beyond-the-Rails™ Medium Voltage Multiplexer and Switches Eliminating the need for multiple voltage output power supplies or additional boost circuitry for the higher voltage rails.
