ED-HMI3010 Raspberry Pi 5 Industrial HMI Series

The EDATEC ED-HMI3010 family scales from compact operator panels to large-format process dashboards, offering five capacitive multitouch LCD sizes: 7", 10.1", 11.6", 13.3", 15.6", and 18.5". All variants share a CNC-machined aluminum bezel plus a sheet-metal rear enclosure that remains completely fanless yet dissipates heat across an operating range of -20°C to +60°C. An IP-rated front seal protects the high-luminance, wide-view TFT from dust, oil, and moisture in factory-floor or outdoor applications.

At the core sits a standard Raspberry Pi 5 running the official 32- or 64-bit Raspberry Pi OS. Memory options span 2 GB to 16 GB LPDDR4X, while storage can be micro-SD, onboard eMMC, or an internal M.2 SATA/NVMe SSD, ensuring fast boot times and high-endurance data logging. Developers gain immediate access to Python, Node-RED, Ignition Edge, Docker, and AI frameworks while maintaining real-time industrial credibility.

I/O is consistent across all screen sizes:

• Network: Gigabit Ethernet standard, optional 4G LTE, or dual-band Wi-Fi/BT
• Two USB 3.0 and two USB 2.0 connectors for cameras, barcode readers, or license dongles
• Serial and Fieldbus: RS-232, RS-485 (isolated), CAN, and eight DI/DO on pluggable headers
• Expansion: full-size PCIe slot (via adapter) for AI accelerators or additional LAN
• Power: 9 V_DC to 36 V_DC input with reverse-polarity and surge protection; optional PoE module

Whether the application demands a palm-sized 7" pendant or an 18.5" overview display, ED-HMI3010 units mount identically, with embedded front frame, or 75/100 mm VESA for seamless scalability from machine-level HMI to plant-wide visualization.
