            LTC6078/LTC6079 Precision Amplifiers
                    Analog Devices' LTC6078/LTC6079 micropower precision, dual CMOS, rail-to-rail input and output amplifiers


Image of Analog Devices' LTC6078/LTC6079 Precision Amplifiers ADI's LTC6078 and LTC6079 are dual/quad, low offset, low noise operational amplifiers with low power consumption and rail-to-rail input/output swing. Input offset voltage is trimmed to less than 25 μV, and the CMOS inputs draw less than 50 pA of bias current. The low offset drift, excellent CMRR, and high voltage gain make them a good choice for precision signal conditioning. Each amplifier draws only 54 μA current on a 3 V supply. The micropower, rail-to-rail operation of the LTC6078 and LTC6079 is well suited for portable instruments and single supply applications. The LTC6078 and LTC6079 are specified on power supply voltages of 3 V and 5 V from -40°C to +125°C. The dual amplifier LTC6078 is available in 8-lead MSOP and 10-lead DFN packages. The quad amplifier LTC6079 is available in 16-lead SSOP and DFN packages.

Features

Maximum offset voltage of 25 µV (25°C)
Maximum offset drift of 0.7 µV/°C
Maximum input bias

1 pA (25°C)
50 pA (≤85°C)

Micropower: 54 µA per amp
95 dB CMRR (min)

100 dB PSRR (min)
Input noise voltage density: 16 nV/√Hz
Rail-to-rail inputs and outputs
2.7 V to 5.5 V operation voltage
LTC6078 available in 8-lead MSOP and 10-lead DFN packages; LTC6079 available in 16-lead SSOP and DFN packages

Applications

Photodiode amplifiers
High impedance sensor amplifiers
Microvolt accuracy threshold detection

Instrumentation amplifiers
Battery-powered applications

LTC6078/LTC6079 Precision Amplifiers

Manufacturer Part Number	Description	Slew Rate	Operating Temperature	Package / Case	Available Quantity	Price	View Details
LTC6078CDD#TRPBF	IC CMOS 2 CIRCUIT 10DFN	0.05V/µs	-40°C ~ 85°C	10-WFDFN Exposed Pad	7996 - Immediate	$49.27	View Details
LTC6078IMS8#TRPBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 85°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	9029 - Immediate	$54.27	View Details
LTC6078IMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 85°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	4641 - Immediate	$54.27	View Details
LTC6078HMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 125°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	735 - Immediate	$54.27	View Details
LTC6078IDD#PBF	IC CMOS 2 CIRCUIT 10DFN	0.05V/µs	-40°C ~ 85°C	10-WFDFN Exposed Pad	3837 - Immediate	$46.15	View Details
LTC6078ACMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 85°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	550 - Immediate	$65.85	View Details
LTC6079CGN#PBF	IC CMOS 4 CIRCUIT 16SSOP	0.05V/µs	-40°C ~ 85°C	16-SSOP (0.154", 3.90mm Width)	718 - Immediate	$71.68	View Details
LTC6079CDHC#PBF	IC CMOS 4 CIRCUIT 16DFN	0.05V/µs	-40°C ~ 85°C	16-WFDFN Exposed Pad	515 - Immediate	$71.68	View Details
LTC6078AIMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 85°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	230 - Immediate	$72.91	View Details
LTC6079IGN#PBF	IC CMOS 4 CIRCUIT 16SSOP	0.05V/µs	-40°C ~ 85°C	16-SSOP (0.154", 3.90mm Width)	48 - Immediate	$79.15	View Details
LTC6078CDD#PBF	IC CMOS 2 CIRCUIT 10DFN	0.05V/µs	-40°C ~ 85°C	10-WFDFN Exposed Pad	525 - Immediate	$49.27	View Details
LTC6078AHMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 125°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	292 - Immediate	$72.91	View Details
LTC6079IDHC#PBF	IC CMOS 4 CIRCUIT 16DFN	0.05V/µs	-40°C ~ 85°C	16-WFDFN Exposed Pad	335 - Immediate	$79.15	View Details
LTC6078HMS8#TRPBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 125°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	2655 - Immediate	$54.27	View Details
LTC6078ACMS8#TRPBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	-40°C ~ 85°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	2705 - Immediate	$65.85	View Details
LTC6079IDHC#TRPBF	IC CMOS 4 CIRCUIT 16DFN	0.05V/µs	-40°C ~ 85°C	16-WFDFN Exposed Pad	1931 - Immediate	$79.15	View Details
LTC6078CMS8#TRPBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	0°C ~ 70°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	14018 - Immediate	$49.27	View Details
LTC6078CMS8#PBF	IC CMOS 2 CIRCUIT 8MSOP	0.05V/µs	0°C ~ 70°C	8-TSSOP, 8-MSOP (0.118", 3.00mm Width)	3835 - Immediate	$49.27	View Details
